▶ EngineEngine Manufacturer FPT YANMAR Engine Model R 753 IE4 4TNV98C Engine Type 3-cylinder, FPT turbocharged & aftercooled 4-cylinder, naturally aspirated diesel No. of Cylinders 3 4 Displacement 135.9 in³ 202.5 in³ Rated Engine Speed 2600 rpm 2500 rpm Engine Power (Gross) 60 hp 58.9 hp PTO Power 51 hp 52 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Dry Dual stage cyclonic (resin 6.5") Fuel System Electronic high pressure common rail Common rail direct injection Alternator 75 A 55 A, 12 V ▶ HydraulicsPump Type Engine-driven dual gear-type Not Published Implement Flow 11.9 gpm 9.4 gpm Steering Flow 5.5 gpm 5.3 gpm Total Hydraulic Flow 17.4 gpm (11.9 + 5.5, computed) 14.7 gpm (9.4 + 5.3, computed) Overall Hydraulic Pump Flow Not Published 14.7 gpm (9.4 + 5.3, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 2 No. of Optional Remote Valves 2 1 ▶ Fluid CapacityFuel Tank Capacity 17.2 gal 12.7 gal Coolant Capacity Not Published 7.8 qt Crankcase Capacity Not Published 8.0 qt Transmission / Hydraulic System Capacity Not Published 7.7 gal Front Axle Fluid Capacity Not Published 2.4 gal ▶ PTO & HitchPTO Type Independent Independent (electro-hydraulic) PTO Rear 540 / 540E 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I/II Category I Hitch Lift Capacity Not Published 3,307 lb Hitch Lift Capacity (at 24”) 2,701 lb 2,756 lb Lift Control Type Mechanical Draft Control (MDC), top link sensing Position control ▶ Transmission & DrivetrainTransmission Type 8x8 mechanical shuttle (dry clutch) I-HMT (Integrated Hydro Mechanical Transmission) No. of Speeds 8F/8R 3 ranges (variable speed) Max Travel Speed (Forward) Not Published 18 mph (with R1 tires) Max Travel Speed (Reverse) Not Published 18 mph (with R1 tires) Clutch Dry clutch Clutch-less shifting (i-HMT) Differential Lock & Limited Slip Options Mechanical rear differential lock; MFD engagement mechanical; limited-slip MFD front axle Rear differential lock (foot pedal engagement) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Fully hydraulic power steering Brakes Wet disc Mechanical wet disc Seat Suspension & Adjustability Contoured seat, adjustable Not Published Front Axle Type 2WD or MFD with limited slip 2WD/4WD selectable engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 2WD: 129.5 in; MFD: 134.0 in 132.1 in Overall Width 67.5 in 70.6 in (with R4 tires) Wheelbase 2WD: 77.5 in; MFD: 77.7 in 77.4 in Ground Clearance Not Published 12.8 in (with R4 tires) Min. Turn Radius without Brakes 2WD: 135.8 in; MFD: 190.9 in Not Published Height to Top of ROPS 2WD: 92.7 in; MFD: 97.4 in 95.7 in (with R4 tires) Height to Top of ROPS (folded) 77 in Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2WD: 4,442 lb; MFD: 5,060 lb 4,039 lb (with ROPS, R4 tires, full fluid) Weight with ROPS and Loader Not Published 5,135 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 (bar tread) 2WD or MFD; R4 (industrial tread) MFD R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 2WD: 7.5x16; MFD: 8.3x24 8-16 R1 Agricultural - Rear 13.6x28 14.9-24 R3 Turf - Front Not Published 27x10.5-15 R3 Turf - Rear Not Published 44x18-20 R4 Industrial - Front MFD: 12.5x18 10-16.5 R4 Industrial - Rear MFD: 18.4x24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Compatible loaders: L545, L555 YL610: Skid-steer-style loader quick attachment system Loader Model L545; L555 YL610 Loader Lift Height L545: 106 in; L555: 105 in YL610: 113 in (to bucket pivot pin) Loader Lift Capacity (Full Height) L545 NSL: 1,565 lb; L545 MSL: 2,205 lb; L555 NSL: 1,940 lb; L555 MSL: 2,734 lb YL610: 2,500 lb at pivot pins Loader Breakout Force L545: 3,131 lb; L555: 3,527 lb YL610: 3,969 lb at pivot pins ▶ WarrantyWarranty Length & Coverage Not Published Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours; Attachments: 1-year limited warranty
