▶ EngineEngine Manufacturer FPT John Deere Engine Model Not Published PowerTech 3029H Engine Type 3-cylinder, FPT turbocharged & aftercooled diesel, Tier 4 B/Final Diesel, turbocharged, liquid-cooled No. of Cylinders 3 3 Displacement 178.8 in³ 179 in³ Rated Engine Speed 2300 rpm 2100 rpm Engine Power (Gross) 64 hp 65 hp PTO Power 50 hp 48.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Two paper elements Fuel System Electronic high pressure common rail Not Published Alternator 120 A 40 A ▶ HydraulicsPump Type Fixed displacement Not Published Implement Flow 12.6 gpm 11.4 gpm Steering Flow Not Published 6.8 gpm Total Hydraulic Flow Not Published 18.2 gpm Overall Hydraulic Pump Flow Not Published 18.2 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves 3 2 ▶ Fluid CapacityFuel Tank Capacity 21.7 gal OOS: 18.0 gal; Cab: 21.6 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published 9 qt Transmission / Hydraulic System Capacity Not Published 2WD: 10 gal; 4WD: 10.3 gal Front Axle Fluid Capacity Not Published 4.8 qt ▶ PTO & HitchPTO Type Independent OOS: Independent, mechanical actuation; Cab: Independent, mechanical or electrohydraulic actuation PTO Rear 540 (standard); 540/540E (optional) 540 rpm (540E optional with PowrReverser) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category 1/2 Category 2, convertible to 1 Hitch Lift Capacity 5,952 lb (optional hitch 6,614 lb) Not Published Hitch Lift Capacity (at 24”) 4,300 lb (optional hitch 4,740 lb) 3,192 lb Lift Control Type Mechanical Draft Control (MDC), top link sensing Position control with top link draft sensing ▶ Transmission & DrivetrainTransmission Type MFD: 12x12 power shuttle (wet clutch); 2WD: 8x8 mechanical shuttle (dry clutch); optional 12x12 mechanical shuttle (dry clutch) or 12x12 with creeper (20x20) SyncShuttle (standard); PowrReverser (optional) No. of Speeds MFD: 12F/12R; 2WD: 8F/8R; optional 12F/12R mechanical or 20F/20R creeper 9F/3R (SyncShuttle); 12F/12R (PowrReverser optional) Max Travel Speed (Forward) 18.6 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch MFD: wet clutch (12x12 power shuttle); 2WD: dry clutch (8x8 mechanical shuttle) Dry (SyncShuttle); Dry/Wet with 12F/12R PowrReverser Differential Lock & Limited Slip Options Mechanical rear differential lock; MFD engagement electrohydraulic; limited-slip MFD front axle Rear diff lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power steering Brakes Wet disc Hydraulic wet disc brakes Seat Suspension & Adjustability Mechanical contoured seat, adjustable; optional air-ride seat Not Published Front Axle Type 2WD or MFD with limited slip 2WD or MFWD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 155.3 in 137.8 in Overall Width Not Published 57.3 in Wheelbase 2WD: 82.1 in; MFD: 83.6 in 80.7 in Ground Clearance Not Published 2WD: 18.8 in; MFWD: 13.4 in Min. Turn Radius without Brakes Not Published 138 in Height to Top of ROPS Not Published 98.4 in Height to Top of ROPS (folded) Not Published 78.5 in Height to Top of Cab Model 2WD: 98 in; MFD: 100 in 95.6 in ▶ WeightTractor Weight (Base) 2WD Cab: 6,173 lb; 2WD Non-cab: 5,622 lb; MFD Cab: 6,834 lb; MFD Non-cab: 6,283 lb 2WD: 4,634 lb; MFWD: 5,621 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 7,165 lb ▶ Tire OptionsTire Size & Options R-1 (ag tread) bias ply standard; optional R-1W (ag tread) radial Not Published R1 Agricultural - Front 2WD: 9.5L-15; MFD: 11.2x24 2WD: 7.5-16; MFWD: 9.5-24 R1 Agricultural - Rear 2WD: 16.9R28; MFD: 16.9x30 (optional 16.9R28) 16.9-28 R3 Turf - Front Not Published 9.5-16 (4WD) R3 Turf - Rear Not Published 21.5L-16.1 R4 Industrial - Front Not Published 12.5-80-18 (4WD) R4 Industrial - Rear Not Published 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published H240 (NSL or MSL) Loader Model L610 H240NSL Loader Lift Height 130.3 in 131 in Loader Lift Capacity (Full Height) NSL: 1,828 lb; MSL: 3,153 lb 3,671 lb Loader Breakout Force Not Published 4,504 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
