▶ EngineEngine Manufacturer FPT Kubota Engine Model Not Published V2403CR-T Engine Type 3-cylinder, FPT turbocharged & aftercooled diesel, Tier 4 B/Final Liquid-cooled, diesel, 4-cylinder, Turbocharged No. of Cylinders 3 4 Displacement 178.8 in³ 148.6 in³ Rated Engine Speed 2300 rpm 2700 rpm Engine Power (Gross) 64 hp 63.4 hp PTO Power 50 hp 51.8 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Dry-dual element Fuel System Electronic high pressure common rail Common Rail System (CRS), direct injection Alternator 120 A 45 A, 12 V ▶ HydraulicsPump Type Fixed displacement Gear Implement Flow 12.6 gpm 9.5 gpm Steering Flow Not Published 4.9 gpm Total Hydraulic Flow Not Published 14.4 gpm (9.5 + 4.9, computed) Overall Hydraulic Pump Flow Not Published 14.4 gpm (9.5 + 4.9, computed) Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Not Published No. of Optional Remote Valves 3 Maximum 3 (opt) ▶ Fluid CapacityFuel Tank Capacity 21.7 gal 13.5 gal Coolant Capacity Not Published 6.9 qt Crankcase Capacity Not Published 7.4 qt Transmission / Hydraulic System Capacity Not Published 11.6 gal Front Axle Fluid Capacity Not Published 8.9 qt ▶ PTO & HitchPTO Type Independent Live independent, hydraulic PTO with PTO brake, wet clutch PTO Rear 540 (standard); 540/540E (optional) 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category 1/2 I & II Hitch Lift Capacity 5,952 lb (optional hitch 6,614 lb) 2870 lb Hitch Lift Capacity (at 24”) 4,300 lb (optional hitch 4,740 lb) 2310 lb Lift Control Type Mechanical Draft Control (MDC), top link sensing Position (std), Draft (opt) ▶ Transmission & DrivetrainTransmission Type MFD: 12x12 power shuttle (wet clutch); 2WD: 8x8 mechanical shuttle (dry clutch); optional 12x12 mechanical shuttle (dry clutch) or 12x12 with creeper (20x20) Hydrostatic transmission No. of Speeds MFD: 12F/12R; 2WD: 8F/8R; optional 12F/12R mechanical or 20F/20R creeper 3-range Max Travel Speed (Forward) 18.6 mph 17.7 mph Max Travel Speed (Reverse) Not Published 16.0 mph Clutch MFD: wet clutch (12x12 power shuttle); 2WD: dry clutch (8x8 mechanical shuttle) No clutch Differential Lock & Limited Slip Options Mechanical rear differential lock; MFD engagement electrohydraulic; limited-slip MFD front axle Rear differential lock standard (mechanical) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic power steering Brakes Wet disc Mechanical wet disc Seat Suspension & Adjustability Mechanical contoured seat, adjustable; optional air-ride seat High-back suspension seat (optional arm rests) Front Axle Type 2WD or MFD with limited slip Bevel gear type (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1650 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 155.3 in 125.9 in (without 3-point hitch) Overall Width Not Published 69.7 in Wheelbase 2WD: 82.1 in; MFD: 83.6 in 74.6 in Ground Clearance Not Published 15.2 in Min. Turn Radius without Brakes Not Published 8.9 ft (with brake applied) Height to Top of ROPS Not Published 95.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 2WD: 98 in; MFD: 100 in 92.7 in ▶ WeightTractor Weight (Base) 2WD Cab: 6,173 lb; 2WD Non-cab: 5,622 lb; MFD Cab: 6,834 lb; MFD Non-cab: 6,283 lb 3,734 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R-1 (ag tread) bias ply standard; optional R-1W (ag tread) radial Standard ag: 9.5-16 / 14.9-26 R1 Agricultural - Front 2WD: 9.5L-15; MFD: 11.2x24 9.5-16 R1 Agricultural - Rear 2WD: 16.9R28; MFD: 16.9x30 (optional 16.9R28) 14.9-26 R3 Turf - Front Not Published 29x12.50-15 R3 Turf - Rear Not Published 44x18-20 R4 Industrial - Front Not Published 12-16.5 R4 Industrial - Rear Not Published 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published 1065A: 2-Lever Quick Coupler for Loader Attachment Loader Model L610 LA1065 Loader Lift Height 130.3 in 111.2 in Loader Lift Capacity (Full Height) NSL: 1,828 lb; MSL: 3,153 lb 2275 lb Loader Breakout Force Not Published 3102 lbf (19.7 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 2000 hours; Limited Powertrain: 72 months or 3000 hours. Commercial Use - Basic Standard Limited: 24 months or 2000 hours; Limited Powertrain: 36 months or 3000 hours. ▶ ITC Company AccessoriesAccessories that fit None tagged yet
