▶ EngineEngine Manufacturer FPT John Deere Engine Model Not Published PowerTech 3029H Engine Type Turbocharged diesel Diesel, turbocharged, liquid-cooled No. of Cylinders 4 3 Displacement 207 in³ 179 in³ Rated Engine Speed 2300 rpm 2100 rpm Engine Power (Gross) 64 hp 65 hp PTO Power 50 hp 48.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Not Published Two paper elements Fuel System Common rail Not Published Alternator Not Published 40 A ▶ HydraulicsPump Type Dual gear pumps Not Published Implement Flow 12.9 gpm 11.4 gpm Steering Flow 7.3 gpm 6.8 gpm Total Hydraulic Flow Not Published 18.2 gpm Overall Hydraulic Pump Flow Not Published 18.2 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves 3 2 ▶ Fluid CapacityFuel Tank Capacity 23.8 gal OOS: 18.0 gal; Cab: 21.6 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published 9 qt Transmission / Hydraulic System Capacity Not Published 2WD: 10 gal; 4WD: 10.3 gal Front Axle Fluid Capacity Not Published 4.8 qt ▶ PTO & HitchPTO Type Independent OOS: Independent, mechanical actuation; Cab: Independent, mechanical or electrohydraulic actuation PTO Rear 540 rpm (540/540E optional) 540 rpm (540E optional with PowrReverser) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I/II Category 2, convertible to 1 Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 3,956 lb 3,192 lb Lift Control Type Mechanical draft control (MDC), top link sensing Position control with top link draft sensing ▶ Transmission & DrivetrainTransmission Type Standard: 12x12 power shuttle (wet clutch); Optional: 12x12 power shuttle (wet clutch) with creeper (20x20) SyncShuttle (standard); PowrReverser (optional) No. of Speeds Standard: 12 forward / 12 reverse; Optional creeper: 20 forward / 20 reverse 9F/3R (SyncShuttle); 12F/12R (PowrReverser optional) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Wet clutch Dry (SyncShuttle); Dry/Wet with 12F/12R PowrReverser Differential Lock & Limited Slip Options Mechanical rear differential lock; limited-slip MFD front axle Rear diff lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Hydraulic wet disc Hydraulic wet disc brakes Seat Suspension & Adjustability Not Published Not Published Front Axle Type 2WD: 2WD front axle; MFD: MFD with limited slip, electrohydraulic engagement 2WD or MFWD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 145.8 in 137.8 in Overall Width 76 in 57.3 in Wheelbase 2WD: 85.8 in; MFD: 84 in 80.7 in Ground Clearance Not Published 2WD: 18.8 in; MFWD: 13.4 in Min. Turn Radius without Brakes Not Published 138 in Height to Top of ROPS Not Published 98.4 in Height to Top of ROPS (folded) Not Published 78.5 in Height to Top of Cab Model 98 in 95.6 in ▶ WeightTractor Weight (Base) Cab 2WD: 6,063 lb; Cab MFD: 6,548 lb 2WD: 4,634 lb; MFWD: 5,621 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 7,165 lb ▶ Tire OptionsTire Size & Options 18.4R34 rear Not Published R1 Agricultural - Front Not Published 2WD: 7.5-16; MFWD: 9.5-24 R1 Agricultural - Rear Not Published 16.9-28 R3 Turf - Front Not Published 9.5-16 (4WD) R3 Turf - Rear Not Published 21.5L-16.1 R4 Industrial - Front Not Published 12.5-80-18 (4WD) R4 Industrial - Rear Not Published 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Compatible with L565 loader H240 (NSL or MSL) Loader Model L565 H240NSL Loader Lift Height 105 in 131 in Loader Lift Capacity (Full Height) 2,734 lb 3,671 lb Loader Breakout Force 3,527 lb 4,504 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
