▶ EnginePTO Power 61 hp 49 hp Alternator Not Published 60 A, 12 V Air Cleaner Not Published Dry type with safety element Engine Type Diesel, turbocharged & aftercooled (intercooled) Diesel, turbocharged and aftercooled Fuel System Not Published Electronically controlled, high-pressure common rail Displacement 134.3 in³ 179 in³ No. of Cylinders 3 3 Rated Engine Speed 2600 rpm 2100 rpm Cooling System Type Not Published Liquid cooled with overflow reservoir Engine Manufacturer FPT Industrial John Deere PowerTech 3029 EWR Engine Power (Gross) 70 hp 68.6 hp @ 100 rpm Engine Emissions Constraints Tier 4 Tier 4 ▶ WeightWeight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Applicable Not Published ▶ WarrantyWarranty Length & Coverage Not Published 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) ▶ HydraulicsPump Type Not Published Tandem gear pump (implement + steering) Steering Flow Not Published 6.8 gpm Implement Flow 11.9 gpm 11.4 gpm Total Hydraulic Flow Not Published 18.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 11.4 gpm at a single rear SCV Overall Hydraulic Pump Flow Not Published 18.2 gpm No. of Optional Remote Valves 2 2 No. of Standard Remote Valves 1 1 ▶ PTO & HitchPTO Rear 540 / 540E 540 @ 2083 engine rpm; 540E @ 1588 engine rpm PTO Type Independent Independent PTO: 540 (SyncShuttle); 540/540E (PowrReverser) Lift Control Type Mechanical draft control (MDC) top link sensing Position and draft control; adjustable rate of drop Hitch Lift Capacity Not Published 3,968 lb @ hitch points Mid-PTO Availability Not Published Not Applicable Category, 3-Point Hitch Category I/II Category II; convertible to Category I Hitch Lift Capacity (at 24”) 2,701 lb 3,197 lb @ 24 in behind hitch balls ▶ Tire OptionsR3 Turf - Rear Not Published 41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium) R3 Turf - Front Not Published 33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium) Tire Size & Options Not Published R1 Ag / R3 Turf / R4 Industrial / Snow R4 Industrial - Rear Not Published 4.6 gal-24 8PR R4; 5.2 gal-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4 R4 Industrial - Front Not Published 27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4 R1 Agricultural - Rear Not Published 14.9-28 6PR R1; 16.9-28 6PR R1; 16.9-30 6PR R1; 18.4-30 6PR R1; 460/85R30 R1; 460/85R30 R1W R1 Agricultural - Front Not Published 9.5-24 10PR R1; 12.4-24 8PR R1; 320/85R24 R1; 320/85R24 R1W ▶ Fluid CapacityCoolant Capacity Not Published Open operator station: 2.85 gal; Cab: 3.08 gal Crankcase Capacity Not Published 9.0 qt (with filter) Fuel Tank Capacity 17.2 gal Open operator station: 15.6 ± 0.44 gal (71 ± 0.5 gal); Cab: 17.59 ± 0.44 gal (80 ± 0.5 gal) Front Axle Fluid Capacity Not Published DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side Transmission / Hydraulic System Capacity Not Published 8.36 gal (9x3); 9.46 gal (12x12) ▶ Loader & AttachmentsLoader Lift Height L545: 106 in; L555: 105 in 124 in Loader Breakout Force L545: up to 3,131 lb; L555: up to 3,527 lb 4,354 lb (measured at pivot) Quick Attach Loader System Not Published Parkable loader (parking system; no tools required for removal/installation); optional John Deere skid steer attachment carrier (tool-free attachment changes) Loader Lift Capacity (Full Height) L545: up to 2,205 lb; L555: up to 2,734 lb 3,225 lb (measured at pivot) ▶ Transmission & DrivetrainClutch Dry clutch Dual clutch, 11 in (PowrReverser) No. of Speeds 8F/8R 9 forward / 3 reverse (SyncShuttle); 12 forward / 12 reverse (PowrReverser) Transmission Type 8x8 mechanical shuttle SyncShuttle 9F/3R (standard); PowrReverser 12F/12R (optional) Max Travel Speed (Forward) Not Published 15.5 mph (SyncShuttle); 20.5 mph (PowrReverser) Max Travel Speed (Reverse) Not Published 14.2 mph (SyncShuttle); 22.3 mph (PowrReverser) Differential Lock & Limited Slip Options Mechanical differential lock; limited slip front axle Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsBrakes Not Published Hydraulically actuated wet disk brakes (oil-immersed) Steering Not Published Hydrostatic power steering Frame Type Not Published Not Published Front Axle Type 2WD or MFD with limited slip 2WD (standard) or MFWD (optional) Drawbar Capacity Not Published 1,675 lb (fully extended); 2,470 lb (short position) Front Axle Rating Not Published Up to 9,612 lb (max permissible MFWD axle load w/ loader; varies by tire) Seat Suspension & Adjustability Not Published Mechanical suspension with weight adjustment; fore/aft and backrest angle adjustment ▶ Dimensions & ManeuverabilityWheelbase 96.5 in / 97.6 in 80.7 in Overall Width Not Published Not Published Ground Clearance Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of Cab Model Not Applicable Not Published Height to Top of ROPS (folded) 77 in Not Published Min. Turn Radius without Brakes Not Published 137.8 in (2WD); 183.1 in (4WD) Overall Length with 3-Point Hitch 129.5 in / 134.0 in 143.3 in
