▶ EngineEngine Manufacturer FPT Kubota Engine Model Not Published V3307-CR-TE4 Engine Type 3-cylinder, FPT turbocharged & aftercooled Liquid-cooled, diesel, 4-cylinder, Turbocharged No. of Cylinders 3 4 Displacement 135.9 in³ 203 in³ Rated Engine Speed 2600 rpm 2400 rpm Engine Power (Gross) 70 hp 72.1 hp PTO Power 62 hp 62 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry paper, dual element, 8 in diameter, with pre-cleaner Fuel System Electronic high pressure common rail Common Rail System (CRS) Alternator 75 A 45 A, 12 V ▶ HydraulicsPump Type Engine-driven dual gear-type Gear Implement Flow 11.9 gpm 11.0 gpm Steering Flow 5.5 gpm 6.1 gpm Total Hydraulic Flow 17.4 gpm (11.9 + 5.5, computed) 17.1 gpm Overall Hydraulic Pump Flow Not Published 17.1 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published 11.0 gpm No. of Standard Remote Valves 1 1 (SCD) No. of Optional Remote Valves 2 2nd, 3rd (optional) ▶ Fluid CapacityFuel Tank Capacity 17.2 gal 18.5 gal Coolant Capacity Not Published 8.5 qt Crankcase Capacity Not Published 12.7 qt Transmission / Hydraulic System Capacity Not Published 14.8 gal Front Axle Fluid Capacity Not Published 5.8 qt (differential) plus 3.7 qt (each bevel gear case) ▶ PTO & HitchPTO Type Independent Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540 / 540E 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category 1/2 I / II Hitch Lift Capacity Not Published 4189 lb Hitch Lift Capacity (at 24”) 2,701 lb 3307 lb Lift Control Type Mechanical Draft Control (MDC), top link sensing Position, Draft (Top Link Sensing) & Mixed Control ▶ Transmission & DrivetrainTransmission Type 8x8 mechanical shuttle (dry clutch) Hydraulic-shuttle (F8/R8), fully synchronized (4-speed main) No. of Speeds 8F/8R F8/R8 Max Travel Speed (Forward) Not Published 18.8 mph Max Travel Speed (Reverse) Not Published 18.5 mph Clutch Dry clutch Multiple wet disc Differential Lock & Limited Slip Options Mechanical rear differential lock; MFD engagement mechanical; limited-slip MFD front axle Rear differential lock standard (mechanical) ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS Steering Hydrostatic Hydrostatic power steering Brakes Wet disc Mechanical wet disc Seat Suspension & Adjustability Contoured seat, adjustable Fully adjustable suspension seat (travel, suspension tension, backrest tilt, arm rests); optional air ride seat on cab models Front Axle Type 2WD or MFD with limited slip Bevel gear type with 55 degree turning angle (4WD) Front Axle Rating Not Published 5290 lb (6615 lb with loader) Drawbar Capacity Not Published 2200 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 2WD: 129.5 in; MFD: 134.0 in 138.0 in Overall Width 67.5 in 73.0 in Wheelbase 2WD: 77.5 in; MFD: 77.7 in 83.1 in Ground Clearance Not Published 18.1 in Min. Turn Radius without Brakes 2WD: 135.8 in; MFD: 190.9 in 11.8 ft Height to Top of ROPS 2WD: 92.7 in; MFD: 97.4 in 97.2 in Height to Top of ROPS (folded) 77 in Not Published Height to Top of Cab Model Not Published 101.0 in ▶ WeightTractor Weight (Base) 2WD: 4,442 lb; MFD: 5,060 lb 5027 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 (bar tread) 2WD or MFD; R4 (industrial tread) MFD Standard: 9.5-24 front, 16.9-30 rear R1 Agricultural - Front 2WD: 7.5x16; MFD: 8.3x24 9.5-24 R1 Agricultural - Rear 13.6x28 16.9-30 R3 Turf - Front Not Published 9.5-24 or LSW305-521 R3 Turf - Rear Not Published 18.4-26 or LSW570-648 R4 Industrial - Front MFD: 12.5x18 14-17.5 R4 Industrial - Rear MFD: 18.4x24 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Compatible loaders: L545, L555 LA1154A: 2-Lever Quick Coupler Loader Model L545; L555 LA1154A Loader Lift Height L545: 106 in; L555: 105 in Height position: 132.7 in; Power position: 117.2 in Loader Lift Capacity (Full Height) L545 NSL: 1,565 lb; L545 MSL: 2,205 lb; L555 NSL: 1,940 lb; L555 MSL: 2,734 lb Height position: 2469 lb; Power position: 2928 lb Loader Breakout Force L545: 3,131 lb; L555: 3,527 lb Height position: 4230 lbf; Power position: 5354 lbf ▶ WarrantyWarranty Length & Coverage Not Published 24 months or 2000 hours; Limited Powertrain: 36 months or 3000 hours. ▶ ITC Company AccessoriesAccessories that fit None tagged yet
