▶ EngineEngine Manufacturer FPT Mahindra Engine Model Not Published Not Published Engine Type 3-cylinder, FPT turbocharged & aftercooled Four stroke, turbocharged, intercooled, common rail direct injection, water cooled diesel, comply with US Tier-4 Final No. of Cylinders 3 3 Displacement 135.9 in³ 161.7 in³ Rated Engine Speed 2600 rpm 2100 rpm Engine Power (Gross) 70 hp 71 hp PTO Power 62 hp 61 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry Not Published Fuel System Electronic high pressure common rail Common rail direct injection Alternator 75 A Power Shuttle: 55 A; Power Shuttle Cab: 140 A ▶ HydraulicsPump Type Engine-driven dual gear-type Not Published Implement Flow 11.9 gpm 11.1 gpm Steering Flow 5.5 gpm 4.6 gpm Total Hydraulic Flow 17.4 gpm (11.9 + 5.5, computed) 15.7 gpm Overall Hydraulic Pump Flow Not Published 15.7 gpm Hydraulic System Type Open center Open center with position and draft control, telescoping stabilizers and flex links Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 2 No. of Optional Remote Valves 2 1 ▶ Fluid CapacityFuel Tank Capacity 17.2 gal 23.8 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent 2 speed independent push button type 1 PTO (wet clutch) PTO Rear 540 / 540E 540 @ 1993 rpm and 540E @ 1469 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category 1/2 CAT I & II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 2,701 lb 5952 lb Lift Control Type Mechanical Draft Control (MDC), top link sensing Position and draft control ▶ Transmission & DrivetrainTransmission Type 8x8 mechanical shuttle (dry clutch) Full synchro mesh speed and constant mesh range No. of Speeds 8F/8R 15F / 15R Max Travel Speed (Forward) Not Published 21.4 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Dry clutch Power shuttle with wet clutch and torsional damper Differential Lock & Limited Slip Options Mechanical rear differential lock; MFD engagement mechanical; limited-slip MFD front axle Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic power steering with tiltable steering column Brakes Wet disc Oil immersed brakes, lever actuated parking brake Seat Suspension & Adjustability Contoured seat, adjustable Suspension seat with foldable armrests Front Axle Type 2WD or MFD with limited slip Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 2WD: 129.5 in; MFD: 134.0 in 152.7 in Overall Width 67.5 in 82 in Wheelbase 2WD: 77.5 in; MFD: 77.7 in 87.4 in Ground Clearance Not Published 15.5 in Min. Turn Radius without Brakes 2WD: 135.8 in; MFD: 190.9 in 12.5 ft Height to Top of ROPS 2WD: 92.7 in; MFD: 97.4 in 106 in Height to Top of ROPS (folded) 77 in Not Published Height to Top of Cab Model Not Published 115 in ▶ WeightTractor Weight (Base) 2WD: 4,442 lb; MFD: 5,060 lb 6,548 lb (6075 Power Shuttle); 7,495 lb (6075 Power Shuttle Cab) Weight with ROPS and Loader Not Published 8428 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 (bar tread) 2WD or MFD; R4 (industrial tread) MFD R1 Agricultural, R4 Industrial R1 Agricultural - Front 2WD: 7.5x16; MFD: 8.3x24 11.2 x 24 R1 Agricultural - Rear 13.6x28 16.9 x 30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front MFD: 12.5x18 43 x 16-20 R4 Industrial - Rear MFD: 18.4x24 18.4-28 ▶ Loader & AttachmentsQuick Attach Loader System Compatible loaders: L545, L555 Skid steer attachment system Loader Model L545; L555 Loader 6075L: open station; Loader 6075CL: cab Loader Lift Height L545: 106 in; L555: 105 in Loader 6075L: 133 in; Loader 6075CL: 133 in Loader Lift Capacity (Full Height) L545 NSL: 1,565 lb; L545 MSL: 2,205 lb; L555 NSL: 1,940 lb; L555 MSL: 2,734 lb Loader 6075L: 3,550 lb; Loader 6075CL: 3,550 lb Loader Breakout Force L545: 3,131 lb; L555: 3,527 lb Loader 6075L: 5,000 lb; Loader 6075CL: 5,000 lb ▶ WarrantyWarranty Length & Coverage Not Published 5-year limited powertrain warranty
