▶ EngineEngine Manufacturer FPT FPT Engine Model R 753 IE4 R753 Engine Type 3-cylinder, FPT turbocharged & aftercooled Turbocharged, intercooled 3-cylinder diesel No. of Cylinders 3 3 Displacement 135.9 in³ 136 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 70 hp 70 hp PTO Power 62 hp 62 hp Engine Emissions Constraints Tier 4 Tier 4B Final Cooling System Type Liquid-cooled Not Published Air Cleaner Dry 2-stage Fuel System Electronic high pressure common rail Common rail direct injection (CRDI) Alternator 75 A 75 A ▶ HydraulicsPump Type Engine-driven dual gear-type Dual hydraulic pumps; open center, fixed displacement gear pump Implement Flow 11.9 gpm 12 gpm Steering Flow 5.5 gpm 5.5 gpm Total Hydraulic Flow 17.4 gpm (11.9 + 5.5, computed) 17.5 gpm Overall Hydraulic Pump Flow Not Published 17.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2 2 ▶ Fluid CapacityFuel Tank Capacity 17.2 gal 17.2 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 / 540E 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I/II Category II/I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 2,701 lb 2,701 lb Lift Control Type Mechanical Draft Control (MDC), top link sensing Position control with mechanical draft control ▶ Transmission & DrivetrainTransmission Type 8x8 mechanical shuttle (dry clutch) 8x8 synchronized shuttle No. of Speeds 8F/8R 8F/8R Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry clutch Dry, 11 in organic plate Differential Lock & Limited Slip Options Mechanical rear differential lock; MFD engagement mechanical; limited-slip MFD front axle Mechanical rear differential lock (foot pedal); 4WD front axle with limited slip and front differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Not Published Brakes Wet disc Individual mechanically actuated wet disc Seat Suspension & Adjustability Contoured seat, adjustable Deluxe contoured suspension seat, adjusts to operator height Front Axle Type 2WD or MFD with limited slip 4WD: limited-slip front axle with front differential lock, mechanical engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 67.5 in 67.5 in (shipping width) Wheelbase 2WD: 77.5 in; MFD: 77.7 in ROPS 4WD: 77.6 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 2WD: 135.8 in; MFD: 190.9 in Not Published Height to Top of ROPS 2WD: 92.7 in; MFD: 97.4 in ROPS 4WD: 97.6 in Height to Top of ROPS (folded) 77 in Not Published Height to Top of Cab Model Not Published Not Applicable Overall Length 2WD: 129.5 in; MFD: 134.0 in ROPS 4WD: 134 in ▶ WeightTractor Weight (Base) 2WD: 4,442 lb; MFD: 5,060 lb ROPS 2WD: 4,442 lb (shipping weight); ROPS 4WD: 5,059 lb (shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Applicable ▶ Tire OptionsTire Size & Options R1 (bar tread) 2WD or MFD; R4 (industrial tread) MFD R1 agricultural, R3 turf, R4 industrial R1 Agricultural - Front 2WD: 7.5x16; MFD: 8.3x24 Not Published R1 Agricultural - Rear 13.6x28 14.9x28 R1 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front MFD: 12.5x18 Not Published R4 Industrial - Rear MFD: 18.4x24 18.4x24 R4 ▶ Loader & AttachmentsQuick Attach Loader System Compatible loaders: L545, L555 600TL Series quick-attach loader (611TL, 621TL, 616TL, 626TL) Loader Model L545; L555 611TL, 616TL, 621TL, 626TL (611TL and 621TL non self-leveling; 616TL and 626TL mechanical self-leveling) Loader Lift Height L545: 106 in; L555: 105 in 611TL: 112 in; 616TL: 115 in; 621TL: 119 in; 626TL: 122 in Loader Lift Capacity (Full Height) L545 NSL: 1,565 lb; L545 MSL: 2,205 lb; L555 NSL: 1,940 lb; L555 MSL: 2,734 lb Not Published Loader Breakout Force L545: 3,131 lb; L555: 3,527 lb 611TL: 2,998 lb; 616TL: 3,130 lb; 621TL: 3,086 lb; 626TL: 3,527 lb (at 31.5 in in front of pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
