▶ EngineEngine Manufacturer FPT Deutz Engine Model F5DFL463A*F017 n/a Engine Type Turbocharged diesel Not Published No. of Cylinders 4 Not Published Displacement 207 in³ Not Published Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 74 hp 74 hp PTO Power 61 hp 64.1 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Not Published Not Published Air Cleaner Not Published Not Published Fuel System Common rail Not Published Alternator Not Published Not Published ▶ HydraulicsPump Type Dual gear pumps Not Published Implement Flow 12.9 gpm 10.3 gpm Steering Flow 7.3 gpm 5.8 gpm Total Hydraulic Flow Not Published 16.1 gpm Overall Hydraulic Pump Flow Not Published 16.1 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves 3 Not Published ▶ Fluid CapacityFuel Tank Capacity 23.8 gal 23.8 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm (540/540E optional) 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I/II Category II Hitch Lift Capacity Not Published 5,115 lb Hitch Lift Capacity (at 24”) 3,956 lb 3,418 lb Lift Control Type Mechanical draft control (MDC), top link sensing Not Published ▶ Transmission & DrivetrainTransmission Type Standard: 12x12 power shuttle (wet clutch); Optional: 12x12 power shuttle (wet clutch) with creeper (20x20) Power shuttle No. of Speeds Standard: 12 forward / 12 reverse; Optional creeper: 20 forward / 20 reverse Not Published Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Wet clutch Wet multi plate Differential Lock & Limited Slip Options Mechanical rear differential lock; limited-slip MFD front axle Rear differential lock (foot pedal engagement) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Not Published Brakes Hydraulic wet disc Not Published Seat Suspension & Adjustability Not Published Mechanical suspension seat Front Axle Type 2WD: 2WD front axle; MFD: MFD with limited slip, electrohydraulic engagement Selectable 2WD/4WD engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 145.8 in Not Published Overall Width 76 in Not Published Wheelbase 2WD: 85.8 in; MFD: 84 in Not Published Ground Clearance Not Published 18.3 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 104.5 in Not Published Height to Top of ROPS (folded) 77.6 in Not Published Height to Top of Cab Model 98 in Not Published ▶ WeightTractor Weight (Base) 6,063 lb n/a Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 18.4R34 rear Not Published R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model L565 n/a Loader Lift Height 105 in 133.8 in Loader Lift Capacity (Full Height) 2,734 lb 3,325 lb Loader Breakout Force 3,527 lb 5,485 lb ▶ WarrantyWarranty Length & Coverage Not Published Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours
