▶ EngineEngine Manufacturer FPT FPT Engine Model F5D Not Published Engine Type Turbocharged and intercooled 4-cylinder diesel 4-cylinder diesel No. of Cylinders 4 4 Displacement 207 in³ 207 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 98 hp 117 hp PTO Power 82 hp 100 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dual dry element Not Published Fuel System Electronic high-pressure common rail direct injection High-pressure common rail electronic direct injection Alternator 120 A Not Published ▶ HydraulicsPump Type Dual engine-driven pumps (open center) Not Published Implement Flow 12.5 gpm (16.9 gpm optional) 16.9 gpm Steering Flow 7.3 gpm 9.7 gpm Total Hydraulic Flow 19.8 gpm (12.5 + 7.3, computed) 26.6 gpm (16.9 + 9.7, computed) Overall Hydraulic Pump Flow 19.8 gpm (12.5 + 7.3, computed) 26.6 gpm (16.9 + 9.7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 2 No. of Optional Remote Valves 2 (3rd remote available through Parts Division) 3 (3rd through Parts) ▶ Fluid CapacityFuel Tank Capacity 30.3 gal 42.3 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent, mechanical engagement Independent PTO Rear 540/1000 (base); 540 (optional) Not Published Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (ball ends convert to Category I) Category II with flex link ends Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 5,620 lb 4,339 lb (5,620 lb with auxiliary lift ram) Lift Control Type Single-lever position control with draft-sensing top link Mechanical draft control (MDC), top link sensing (12x12); electronic draft control (EDC), lower link sensing (Hi-Lo cab) ▶ Transmission & DrivetrainTransmission Type Not Published Not Published No. of Speeds 12F/12R (20F/12R or 20F/20R with creeper optional) 12F/12R (20F/20R creeper, 24F/24R Hi-Lo or 40F/40R Hi-Lo creeper optional) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Wet clutch (power shuttle and Hi-Lo) Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical rear differential lock (12x12); electrohydraulic (Hi-Lo); MFD front axle with limited slip ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc (mechanical on ROPS, hydraulic on cab) Wet disc Seat Suspension & Adjustability Air suspension seat with 15-degree swivel (optional, cab) Air suspension seat with 15-degree swivel (optional); instructional seat (optional) Front Axle Type 2WD or MFD (mechanical front drive) HD 2WD, MFD or HD MFD with limited slip (12x12); HD MFD with limited slip (Hi-Lo) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 149 in (MFD cab, 16.9R-34 rear tires) 160 in (MFD cab) Overall Width 83 in 76 in (across standard fenders) Wheelbase 89 in (MFD) 90 in (MFD) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 103 in 106 in (18.4R34 rear tires) Height to Top of ROPS (folded) Not Published 82.9 in (18.4R34 rear tires) Height to Top of Cab Model 100 in 102 in ▶ WeightTractor Weight (Base) 7,937 lb (MFD cab, 16.9R-34 rear tires) Not Published Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 agricultural or turf, radial or bias; 18.4R34 rear reference tire R1 Agricultural - Front Not Published 7.50-16 (2WD); 11.2R24 or 14.9R24 (4WD) R1 Agricultural - Rear 16.9R-34 18.4R34 (reference tire) R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid steer-style quick attach (hydraulic coupler) Not Published Loader Model L620; L630; L735 L620; L630 Loader Lift Height L620: 126.3 in (NSL) / 125.9 in (MSL); L630: 134 in (NSL) / 135 in (MSL); L735: 137 in L620: 126.3 in (NSL) / 125.9 in (MSL); L630: 134 in (NSL) / 135 in (MSL) Loader Lift Capacity (Full Height) L620: 3,461 lb (NSL) / 3,573 lb (MSL); L630: 3,849 lb (NSL) / 4,204 lb (MSL); L735: 4,034 lb (NSL) / 3,505 lb (MSL) L620: 2,478 lb (NSL) / 3,179 lb (MSL); L630: 2,632 lb (NSL) / 3,428 lb (MSL) (at 31.5 in forward of pivot pin) Loader Breakout Force L620: 5,530 lb (NSL) / 5,483 lb (MSL); L630: 6,649 lb (NSL) / 6,767 lb (MSL); L735: 4,960 lb (NSL) / 4,122 lb (MSL) Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
