▶ EngineEngine Manufacturer FPT FPT Engine Model F5D Not Published Engine Type Turbocharged and intercooled 4-cylinder diesel Turbocharged diesel No. of Cylinders 4 4 Displacement 207 in³ 207.5 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 98 hp 74 hp PTO Power 82 hp 61 hp Engine Emissions Constraints Tier 4A Tier 4 Cooling System Type Liquid-cooled Not Published Air Cleaner Dual dry element Not Published Fuel System Electronic high-pressure common-rail fuel injection Common rail Alternator 120 A Not Published ▶ HydraulicsPump Type Dual engine-driven pumps (open center) Dual gear pumps Implement Flow 12.5 gpm (16.9 gpm optional) 12.9 gpm Steering Flow 7.3 gpm 7.3 gpm Total Hydraulic Flow 19.8 gpm (12.5 + 7.3, computed) Not Published Overall Hydraulic Pump Flow 19.8 gpm (12.5 + 7.3, computed) Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 2 No. of Optional Remote Valves 2 (3rd remote available through Parts Division) 1 ▶ Fluid CapacityFuel Tank Capacity 30.3 gal 23.8 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent, mechanical engagement Independent PTO Rear 540/1000 (base); 540 (optional) 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (ball ends convert to Category I) Category I/II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 5,620 lb 3,956 lb Lift Control Type Single-lever position control with draft-sensing top link Mechanical draft control (MDC), top link sensing ▶ Transmission & DrivetrainTransmission Type Not Published Standard: 12x12 power shuttle (wet clutch); Optional: 12x12 power shuttle (wet clutch) with creeper (20x20) No. of Speeds 12F/12R mechanical (20F/12R mechanical with creeper; 12F/12R power shuttle; 20F/20R optional) Standard: 12 forward and 12 reverse; Optional creeper: 20 forward and 20 reverse Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Wet clutch Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical; MFD front axle with limited slip ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet disc (mechanical on ROPS, hydraulic on cab) Hydraulic wet disc Seat Suspension & Adjustability Air suspension seat with 15-degree swivel (optional, cab) Not Published Front Axle Type 2WD or MFD MFD with limited slip; electrohydraulic engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 83 in 76 in Wheelbase 89 in (MFD) 84 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 103 in Not Applicable Height to Top of ROPS (folded) Not Published Not Applicable Height to Top of Cab Model 100 in 98 in Overall Length 149 in (MFD cab, 16.9R-34 rear tires) 145.8 in ▶ WeightTractor Weight (Base) 7,937 lb (MFD cab, 16.9R-34 rear tires) 6,548 lb (weight w/o ballast) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published 18.4R34 rear R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear 16.9R-34 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid steer-style quick attach (hydraulic coupler) L565 Loader Model L620; L630; L735 L565 Loader Lift Height L620: 126.3 in (NSL) / 125.9 in (MSL); L630: 134 in (NSL) / 135 in (MSL); L735: 137 in L565: 105 in Loader Lift Capacity (Full Height) L620: 3,461 lb (NSL) / 3,573 lb (MSL); L630: 3,849 lb (NSL) / 4,204 lb (MSL); L735: 4,034 lb (NSL) / 3,505 lb (MSL) (maximum height at pins) L565: 2,734 lb Loader Breakout Force L620: 5,530 lb (NSL) / 5,483 lb (MSL); L630: 6,649 lb (NSL) / 6,767 lb (MSL); L735: 4,960 lb (NSL) / 4,122 lb (MSL) (breakout at pins) L565: 3,527 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
