▶ EngineEngine Manufacturer FPT John Deere Engine Model F5D PowerTech 4045 PWL Engine Type Turbocharged and intercooled 4-cylinder diesel Diesel, turbocharged, air-to-air aftercooled No. of Cylinders 4 4 Displacement 207 in³ 276 in³ Rated Engine Speed 2300 rpm 2100 rpm Engine Power (Gross) 98 hp 99.1 hp PTO Power 82 hp 85 hp @ 100 rpm Engine Emissions Constraints Tier 4A Tier 4 Cooling System Type Liquid-cooled Liquid-cooled (Cool-Gard II coolant) Air Cleaner Dual dry element Dry air cleaner, primary and secondary elements Fuel System Electronic high-pressure common-rail fuel injection High pressure common rail (HPCR); electronic fuel control Alternator 120 A OOS: 90 A; Cab: 120 A; Field-installed option: 200 A, 12 V ▶ HydraulicsPump Type Dual engine-driven pumps (open center) Tandem gear pump Implement Flow 12.5 gpm (16.9 gpm optional) 18.4 gpm Steering Flow 7.3 gpm 6.3 gpm Total Hydraulic Flow 19.8 gpm (12.5 + 7.3, computed) 24.7 gpm Overall Hydraulic Pump Flow 19.8 gpm (12.5 + 7.3, computed) 24.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 2 (rear, Dual SCV) No. of Optional Remote Valves 2 (3rd remote available through Parts Division) 3 rear valves total (3rd rear SCV optional); up to 3 mid SCVs (XI, XII, XIII) for loader functions ▶ Fluid CapacityFuel Tank Capacity 30.3 gal OOS: 29.6 gal; OOS (High Capacity): 37.2 gal; Cab: 37 gal; Cab (High Capacity): 44.9 gal Coolant Capacity Not Published OOS: 5.2 gal; Cab: 5.8 gal Crankcase Capacity Not Published 3.4 gal Transmission / Hydraulic System Capacity Not Published 10.4 gal Front Axle Fluid Capacity Not Published Differential housing (MFWD): 1.3 gal; Wheel hub (each): 0.2 gal ▶ PTO & HitchPTO Type Independent, mechanical engagement Independent rear PTO, electro-hydraulic wet disc clutch: 540/540E standard, 540/540E/1000 optional PTO Rear 540/1000 (base); 540 (optional) 540/540E rpm standard; 1000 rpm optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (ball ends convert to Category I) Category II (convertible to I) Hitch Lift Capacity Not Published 5,305 lb standard; 6,114 lb optional Hitch Lift Capacity (at 24”) 5,620 lb 5,159 lb standard; 5,954 lb optional Lift Control Type Single-lever position control with draft-sensing top link Mechanical or electrohydraulic; lower-link draft sensing ▶ Transmission & DrivetrainTransmission Type Not Published PowrReverser 16F/16R (base); optional 32F/16R PowrReverser Hi-Lo; PowrQuad PLUS 16F/16R and Powr8 32F/16R also offered No. of Speeds 12F/12R mechanical (20F/12R mechanical with creeper; 12F/12R power shuttle; 20F/20R optional) 16F/16R standard (PowrReverser); 32F/16R optional (PowrReverser Hi-Lo); 16F/16R (PowrQuad PLUS); 32F/16R (Powr8) Max Travel Speed (Forward) Not Published 16F/16R PowrReverser, top gear (D-4): 30K config: 18.64 mph; 40K config: 21.72 mph (480/70R28 Mitas rear tires, 2200 rpm) Max Travel Speed (Reverse) Not Published 16F/16R PowrReverser, top gear (D-4): 30K config: 20.54 mph; 40K config: 23.94 mph (480/70R28 Mitas rear tires, 2200 rpm) Clutch Not Published Wet Differential Lock & Limited Slip Options Mechanical rear differential lock Electro-hydraulic rear differential lock, engage on the go ▶ Chassis, Steering & ControlsFrame Type Not Published Cast iron mid-frame Steering Power steering Not Published Brakes Wet disc (mechanical on ROPS, hydraulic on cab) Not Published Seat Suspension & Adjustability Air suspension seat with 15-degree swivel (optional, cab) OOS: isolated mechanical seat (fore/aft, weight, and lumbar adjustment); Cab: mechanical suspension seat standard, air suspension seat optional; adjustable weight range 88-330 lb Front Axle Type 2WD or MFD MFWD Front Axle Rating Not Published 6,613 lb (MFWD, max permissible front axle load) Drawbar Capacity Not Published Standard drawbar: 2,756 lb; 2,425 lb; 2,205 lb. Heavy-duty drawbar: 3,197 lb; 2,646 lb ▶ Dimensions & ManeuverabilityOverall Width 83 in Cab, with fender extension: 85.6 in; Cab, without fender extension: 74 in; OOS, with fender extension: 69.1 in; OOS, without fender extension: 51.7 in Wheelbase 89 in (MFD) 92.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 103 in 102.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 100 in 102.9 in Overall Length 149 in (MFD cab, 16.9R-34 rear tires) 149.5 in ▶ WeightTractor Weight (Base) 7,937 lb (MFD cab, 16.9R-34 rear tires) 2WD, OOS: 8,140 lb; 2WD, Cab: 8,580 lb; MFWD, OOS: 8,765 lb; MFWD, Cab: 9,185 lb (shipping weight, less weights) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front Not Published 12.4R24 (320/85R24) R1W Radial R1 Agricultural - Rear 16.9R-34 18.4R30 (460/85R30) R1W Radial R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid steer-style quick attach (hydraulic coupler) Not Published Loader Model L620; L630; L735 540M NSL; 540M SL; 540R NSL; 540R SL; H310 NSL (MFWD required for H310) Loader Lift Height L620: 126.3 in (NSL) / 125.9 in (MSL); L630: 134 in (NSL) / 135 in (MSL); L735: 137 in 540M NSL: 138 in; 540M SL: 138 in; 540R NSL: 141 in; 540R SL: 141 in; H310 NSL: 149 in Loader Lift Capacity (Full Height) L620: 3,461 lb (NSL) / 3,573 lb (MSL); L630: 3,849 lb (NSL) / 4,204 lb (MSL); L735: 4,034 lb (NSL) / 3,505 lb (MSL) (maximum height at pins) 540M NSL: 3,674 lb; 540M SL: 3,058 lb; 540R NSL: 4,246 lb; 540R SL: 3,395 lb; H310 NSL: 4,644 lb (measured at pivot) Loader Breakout Force L620: 5,530 lb (NSL) / 5,483 lb (MSL); L630: 6,649 lb (NSL) / 6,767 lb (MSL); L735: 4,960 lb (NSL) / 4,122 lb (MSL) (breakout at pins) 540M NSL: 6,686 lbf; 540M SL: 5,513 lbf; 540R NSL: 4,945 lbf; 540R SL: 5,291 lbf; H310 NSL: 6,767 lbf (measured at pivot) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
