▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV80F-CJT 3TNM74F-CJT Engine Type 3-cylinder, liquid-cooled diesel 3-cylinder, liquid-cooled diesel No. of Cylinders 3 3 Displacement 77.3 in³ 60.6 in³ Rated Engine Speed 3200 rpm 3200 rpm Engine Power (Gross) 23.9 hp 21.5 hp PTO Power 18 hp 14.9 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry with safety element Dry with safety element Fuel System Indirect injection Indirect injection Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Gear Gear Implement Flow 3.3 gpm 3.3 gpm Steering Flow 3.3 gpm 3.3 gpm Total Hydraulic Flow 6.5 gpm 6.5 gpm Overall Hydraulic Pump Flow 6.5 gpm 6.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 3.5 gpm per pump (implement circuit); total system output 6.3 gpm 3.5 gpm implement circuit No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Three 1 additional (optional 3rd SCV kit; standard is 2 mid-SCVs) ▶ Fluid CapacityFuel Tank Capacity 5.6 gal 5.6 gal Coolant Capacity 3.9 qt 3.9 qt Crankcase Capacity 2.9 qt 2.9 qt Transmission / Hydraulic System Capacity 3.25 gal 3.25 gal Front Axle Fluid Capacity 3.0 qt 3.0 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Standard, 2100 rpm Standard, 2100 rpm Category, 3-Point Hitch Limited Category I Limited Category I Hitch Lift Capacity 1177 lb 1177 lb Hitch Lift Capacity (at 24”) 758 lb 758 lb Lift Control Type Position control Select control ▶ Transmission & DrivetrainTransmission Type Hydrostatic - 2 range Hydrostatic - 2 range No. of Speeds Infinite (hydrostatic), 2 ranges forward and reverse Infinite (hydrostatic), 2 ranges forward and reverse Max Travel Speed (Forward) 9.1 mph 9.1 mph Max Travel Speed (Reverse) 9.1 mph 9.1 mph Clutch wet disc Wet disk Differential Lock & Limited Slip Options Standard rear differential lock Standard rear differential lock ▶ Chassis, Steering & ControlsFrame Type Semi-flat platform; two-post folding ROPS; 4WD with mechanical front-wheel drive Open center frame with two-post foldable ROPS Steering Power steering Power steering Brakes Wet disk, left-hand pedal Wet disk, left-hand pedal Seat Suspension & Adjustability Premium seat; adjusts fore/aft; seat flips forward; high seat back and armrests; retractable seat belt Spring suspension seat, adjusts fore/aft Front Axle Type Four-wheel drive (mechanical front-wheel drive, on-the-go engagement) Four-wheel drive (mechanical front-wheel drive, on-the-go engagement) Front Axle Rating 1349 lb 1349 lb Drawbar Capacity 2165 lb 2017 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 108 in 108 in Overall Width 47.22 in (R3 tires); 47.32 in (R4 tires) 47.22 in (R3 tires); 47.32 in (R4 tires) Wheelbase 57.1 in 57.1 in Ground Clearance 9.0 in under the front axle (operator's manual); 7.7 in (Deere website) 9.0 in under the front axle (operator's manual); 7.7 in (Deere website) Min. Turn Radius without Brakes 88.8 in 88.8 in Height to Top of ROPS 90 in 90 in Height to Top of ROPS (folded) 73 in 73 in Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1444 lb 1345 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard R4, optional R3 Standard R4, optional R3 R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front 18x8.5-10 18x8.5-10 R3 Turf - Rear 26x12-12 26x12-12 R4 Industrial - Front 18x8.5-10 18x8.5-10 R4 Industrial - Rear 26x12-12 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System Quik-Park (MSL option on 120R) Quik-Park Loader Model 120R (NSL or MSL) or 120E (D120 and H120 on earlier units) 120R or 120E (D120 and H120 on earlier units) Loader Lift Height 120R (NSL and MSL): 72 in; 120E: 71.2 in; D120 and H120: 71.2 in 120R: 72 in; 120E: 71.2 in; D120 and H120: 71.2 in Loader Lift Capacity (Full Height) 120R NSL: 752 lb (49 in bucket) or 704 lb (53 in bucket); 120R MSL: 548 lb (53 in bucket); D120: 825 lb; H120: 836 lb (all at pivot pin, max height) 120R: 754 lb (49 in bucket) or 706 lb (53 in bucket); D120: 825 lb; H120: 836 lb (all at pivot pin, max height) Loader Breakout Force 120R NSL: 2008 lbf (49 in bucket) or 1816 lbf (53 in bucket); 120R MSL: 1591 lbf; D120: 1808 lbf; H120: 1819 lbf (at pivot pin) 120R: 1823 lbf (49 in bucket) or 1816 lbf (53 in bucket); D120: 1808 lbf; H120: 1819 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-Year / 2,000 Hour Limited Powertrain Warranty; standard at no cost, covers residential and commercial use 6-Year / 2,000 Hour Limited Powertrain Warranty; standard at no cost, covers residential and commercial use
