▶ EngineEngine Manufacturer Yanmar KIOTI Engine Model 3TNV80F-CJT 3C100LFH-U2 Engine Type 3-cylinder, liquid-cooled diesel In-Line Vertical, Water-Cooled Diesel (3-cylinder) No. of Cylinders 3 3 Displacement 77.3 in³ 61.5 in³ Rated Engine Speed 3200 rpm 3200 rpm Engine Power (Gross) 23.9 hp 24.5 hp PTO Power 18 hp 18.5 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Not Published Air Cleaner Dry with safety element Not Published Fuel System Indirect injection Not Published Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Gear Gear Implement Flow 3.5 gpm 7.0 gpm Steering Flow 3.5 gpm Not Published Total Hydraulic Flow 7 gpm 7.0 gpm Overall Hydraulic Pump Flow 6.3 gpm 7.0 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow 3.5 gpm implement circuit; total 7 gpm Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 6.3 gal 6.7 gal Coolant Capacity 3.9 qt 0.87 gal Crankcase Capacity 2.9 qt 1.0 gal Transmission / Hydraulic System Capacity 3.25 gal 2.75 gal Front Axle Fluid Capacity 3.0 qt 0.53 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Standard, 2100 rpm Available (2,200 rpm) Category, 3-Point Hitch Limited Category I Category I Hitch Lift Capacity 1,177 lb 1,580 lb Hitch Lift Capacity (at 24”) 758 lb 700 lb Lift Control Type Position control Position ▶ Transmission & DrivetrainTransmission Type Hydrostatic - 2 range Hydrostatic (HST) No. of Speeds Infinite (hydrostatic), 2 ranges forward and reverse Infinite, 2 range (High/Low) Max Travel Speed (Forward) 9.1 mph 9.6 mph Max Travel Speed (Reverse) 9.1 mph 6.6 mph Clutch wet disc None (hydrostatic transmission) Differential Lock & Limited Slip Options Standard rear differential lock Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Semi-flat platform; two-post folding ROPS; four-wheel drive Not Published Steering Power steering Hydrostatic power steering Brakes Wet disk, left-hand pedal Wet multi disc Seat Suspension & Adjustability Deluxe suspension seat with armrests and tilt steering wheel Not Published Front Axle Type 4WD (MFWD), on-the-go engagement Mechanical 4WD Front Axle Rating 1,349 lb Not Published Drawbar Capacity 2,165 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 47.22 in (R3 tires); 47.32 in (R4 tires) 45.9 in Wheelbase 57.1 in 55.1 in Ground Clearance 7.7 in (front axle) 6.4 in Min. Turn Radius without Brakes 7.4 ft (no brakes, no MFWD) 8.2 ft (with brake applied) Height to Top of ROPS 90 in (ROPS extended, R4 tires) 87.6 in Height to Top of ROPS (folded) 73 in Not Published Height to Top of Cab Model Not Published Not Published Overall Length 108 in 99.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,556 lb 1,554 lb (with AG. tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard R4, optional R3 Agricultural, Turf and Industrial: 18x8.5-10 front, 26x12.00-12 rear R1 Agricultural - Front Not Published 18x8.5-10 R1 Agricultural - Rear Not Published 26x12.00-12 R3 Turf - Front 18x8.5-10 18x8.5-10 R3 Turf - Rear 26x12-12 26x12.00-12 R4 Industrial - Front 18x8.5-10 18x8.5-10 R4 Industrial - Rear 26x12-12 26x12.00-12 ▶ Loader & AttachmentsQuick Attach Loader System Tool-free attach and park (MSL optional on 120R) Quick attach (QA) bucket, 48 in Loader Model 120R (MSL or NSL); 120E (NSL only) SL2420 Loader Lift Height 120R: 72 in; 120E: 71.2 in SL2420: 73.7 in (at pivot pin) Loader Lift Capacity (Full Height) 120R (MSL): 680 lb; 120E (NSL): 519 lb (at 19.7 in ahead of pivot) SL2420: 1,062 lb Loader Breakout Force Not Published SL2420: 1,329 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Powertrain 6 years, standard at no cost, covers residential and commercial use Non-commercial: basic 24 months, powertrain 72 months on qualifying tractors, unlimited hours, parts and labor
