▶ EngineEngine Manufacturer Yanmar Kubota Engine Model 3TNV80F-CJT D1005 Engine Type 3-cylinder, liquid-cooled diesel Liquid-cooled, 4-cycle diesel No. of Cylinders 3 3 Displacement 77.3 in³ 61.1 in³ Rated Engine Speed 3200 rpm 3200 rpm Engine Power (Gross) 23.9 hp 23.3 hp PTO Power 18 hp 19.2 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Water with pressurized radiator, reverse air-flow design Air Cleaner Dry with safety element Dry element Fuel System Indirect injection Direct injection Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Gear Open center tandem pump gear type Implement Flow 3.5 gpm 5.2 gpm Steering Flow 3.5 gpm 1.0 gpm Total Hydraulic Flow 7 gpm 6.2 gpm Overall Hydraulic Pump Flow 6.3 gpm 6.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 3.5 gpm implement circuit; total 7 gpm Not Published No. of Standard Remote Valves Not Published None (2-valve rear remote coupler optional) No. of Optional Remote Valves Not Published 2 (optional; ISO 7241-1 series A or B) ▶ Fluid CapacityFuel Tank Capacity 6.3 gal 6.6 gal Coolant Capacity 3.9 qt 3.5 qt Crankcase Capacity 2.9 qt 4.2 qt Transmission / Hydraulic System Capacity 3.25 gal 3.0 gal Front Axle Fluid Capacity 3.0 qt 3.8 qt ▶ PTO & HitchPTO Type Independent Live independent PTO (with hydraulic clutch) PTO Rear 540 rpm STD (540 rpm) Mid-PTO Availability Standard, 2100 rpm STD (2500 rpm) Category, 3-Point Hitch Limited Category I SAE Category I Hitch Lift Capacity 1,177 lb 1,213 lb Hitch Lift Capacity (at 24”) 758 lb 680 lb Lift Control Type Position control Quarter-inching valve ▶ Transmission & DrivetrainTransmission Type Hydrostatic - 2 range Hydrostatic transmission No. of Speeds Infinite (hydrostatic), 2 ranges forward and reverse 2 Range (Low-High) Max Travel Speed (Forward) 9.1 mph 8.4 mph Max Travel Speed (Reverse) 9.1 mph 6.5 mph Clutch wet disc None (HST) Differential Lock & Limited Slip Options Standard rear differential lock Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Semi-flat platform; two-post folding ROPS; four-wheel drive Two-post foldable ROPS Steering Power steering Hydrostatic type power steering Brakes Wet disk, left-hand pedal Mechanical, wet disc type Seat Suspension & Adjustability Deluxe suspension seat with armrests and tilt steering wheel High-back seat with armrests; fore/aft slide and backrest-tilt adjustment Front Axle Type 4WD (MFWD), on-the-go engagement 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating 1,349 lb Not Published Drawbar Capacity 2,165 lb Max. drawbar load @ hitch: 550 lb ▶ Dimensions & ManeuverabilityOverall Width 47.22 in (R3 tires); 47.32 in (R4 tires) 45.1 in Wheelbase 57.1 in 55.1 in Ground Clearance 7.7 in (front axle) 6.5 in Min. Turn Radius without Brakes 7.4 ft (no brakes, no MFWD) 7.5 ft Height to Top of ROPS 90 in (ROPS extended, R4 tires) 83.1 in Height to Top of ROPS (folded) 73 in Not Published Height to Top of Cab Model Not Published Not Published Overall Length 108 in 95.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,556 lb 1,521 lb (with ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard R4, optional R3 R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front Not Published 18X8.5-10 R1 Agricultural - Rear Not Published 26X12-12 R3 Turf - Front 18x8.5-10 18X8.5-10 R3 Turf - Rear 26x12-12 26X12-12 R4 Industrial - Front 18x8.5-10 18X8.5-10 R4 Industrial - Rear 26x12-12 26X12-12 ▶ Loader & AttachmentsQuick Attach Loader System Tool-free attach and park (MSL optional on 120R) Swift-Tach Loader (LA344S - Two Lever Quick Attach Bucket) Loader Model 120R (MSL or NSL); 120E (NSL only) LA344S (standard, quick attach); LA344 (pin-on option) Loader Lift Height 120R: 72 in; 120E: 71.2 in 71.0 in (at pivot pin) Loader Lift Capacity (Full Height) 120R (MSL): 680 lb; 120E (NSL): 519 lb (at 19.7 in ahead of pivot) 739 lb (LA344 pin-on); 613 lb (LA344S quick attach) Loader Breakout Force Not Published 1,407 lbf (LA344 pin-on); 1,286 lbf (LA344S quick attach) ▶ WarrantyWarranty Length & Coverage Powertrain 6 years, standard at no cost, covers residential and commercial use Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
