▶ EngineEngine Manufacturer Yanmar YANMAR Engine Model 3TNV80F-CJT 3TNV80F Engine Type 3-cylinder, liquid-cooled diesel 4-cycle inline, water-cooled diesel, naturally aspirated No. of Cylinders 3 3 Displacement 77.3 in³ 77.2 in³ Rated Engine Speed 3200 rpm 3200 rpm Engine Power (Gross) 23.9 hp 23.9 hp PTO Power 18 hp 18.1 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Dry with safety element Not Published Fuel System Indirect injection Not Published Alternator 40 A, 12 V 40 A ▶ HydraulicsPump Type Gear Dual hydraulic pump Implement Flow 3.3 gpm 4.3 gpm Steering Flow 3.3 gpm 3.7 gpm Total Hydraulic Flow 6.5 gpm 8.0 gpm (4.3 + 3.7, computed) Overall Hydraulic Pump Flow 6.5 gpm 8.0 gpm (4.3 + 3.7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 3.5 gpm per pump (implement circuit); total system output 6.3 gpm Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Three Not Published ▶ Fluid CapacityFuel Tank Capacity 5.6 gal 6.1 gal Coolant Capacity 3.9 qt 3.0 qt Crankcase Capacity 2.9 qt 3.6 qt Transmission / Hydraulic System Capacity 3.25 gal 4.1 gal Front Axle Fluid Capacity 3.0 qt 3.7 qt ▶ PTO & HitchPTO Type Independent Independent, hydraulic clutch PTO Rear 540 rpm 554 rpm @ 3,200 engine rpm; 1.4 in OD, 6 splines Mid-PTO Availability Standard, 2100 rpm Independent mid-PTO, 2,057 rpm @ 3,200 engine rpm, SAE 16/32, 15 splines Category, 3-Point Hitch Limited Category I Limited Category I Hitch Lift Capacity 1177 lb Not Published Hitch Lift Capacity (at 24”) 758 lb 1,209 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic - 2 range Hydrostatic transmission, dual range speeds No. of Speeds Infinite (hydrostatic), 2 ranges forward and reverse Infinite forward and reverse (hydrostatic); 2 ranges Max Travel Speed (Forward) 9.1 mph 13.1 mph (high range, with R4 tires) Max Travel Speed (Reverse) 9.1 mph 9.1 mph (high range, with R4 tires) Clutch wet disc Not Published Differential Lock & Limited Slip Options Standard rear differential lock Differential lock ▶ Chassis, Steering & ControlsFrame Type Semi-flat platform; two-post folding ROPS; 4WD with mechanical front-wheel drive Full-frame chassis Steering Power steering Hydrostatic power steering Brakes Wet disk, left-hand pedal Wet disc Seat Suspension & Adjustability Premium seat; adjusts fore/aft; seat flips forward; high seat back and armrests; retractable seat belt Fore-and-aft adjustable operator seat Front Axle Type Four-wheel drive (mechanical front-wheel drive, on-the-go engagement) Cast iron, selectable 4WD Front Axle Rating 1349 lb Not Published Drawbar Capacity 2165 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 108 in 105.8 in Overall Width 47.22 in (R3 tires); 47.32 in (R4 tires) 54.1 in (with R4 tires) Wheelbase 57.1 in 63.0 in Ground Clearance 9.0 in under the front axle (operator's manual); 7.7 in (Deere website) 9.9 in (with R4 tires) Min. Turn Radius without Brakes 88.8 in 8.5 ft Height to Top of ROPS 90 in 87.2 in (with R4 tires) Height to Top of ROPS (folded) 73 in 71.8 in (folded ROPS, top of steering wheel, R4 tires) Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1444 lb 1,830 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard R4, optional R3 R3 Turf; R4 Industrial R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front 18x8.5-10 24x8.50-14 4PR R3 Turf - Rear 26x12-12 36x14.00-15 4PR R4 Industrial - Front 18x8.5-10 23x8.50-12 4PR R4 Industrial - Rear 26x12-12 14-17.5 6PR ▶ Loader & AttachmentsQuick Attach Loader System Quik-Park (MSL option on 120R) YL210: YANMAR quick attachment system Loader Model 120R (NSL or MSL) or 120E (D120 and H120 on earlier units) YL210 Loader Lift Height 120R (NSL and MSL): 72 in; 120E: 71.2 in; D120 and H120: 71.2 in YL210: 79 in to pivot pin (58 in under level bucket) Loader Lift Capacity (Full Height) 120R NSL: 752 lb (49 in bucket) or 704 lb (53 in bucket); 120R MSL: 548 lb (53 in bucket); D120: 825 lb; H120: 836 lb (all at pivot pin, max height) YL210: 1,199 lb at pivot pin Loader Breakout Force 120R NSL: 2008 lbf (49 in bucket) or 1816 lbf (53 in bucket); 120R MSL: 1591 lbf; D120: 1808 lbf; H120: 1819 lbf (at pivot pin) YL210: 2,090 lb at pivot pin ▶ WarrantyWarranty Length & Coverage 6-Year / 2,000 Hour Limited Powertrain Warranty; standard at no cost, covers residential and commercial use Tractor (private individual usage): 24 months or 2,000 hours; Powertrain (engine and transmission core components): 10 years or 3,000 hours; Attachments: 1-year limited warranty
