▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNM74F-NCJT 3TNV88F-EPJT2 Engine Type Diesel Diesel, naturally aspirated, direct injection No. of Cylinders 3 3 Displacement 60.6 in³ 95.7 in³ Rated Engine Speed 3200 rpm 2400 rpm Engine Power (Gross) 21.5 hp 24.4 hp PTO Power 16.2 hp 17.4 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Water pump Air Cleaner Not Published Dry type with safety element Fuel System Not Published Direct injection Alternator Not Published 55 A, 12 V ▶ HydraulicsPump Type Gear Implement/steering pump: Tandem gear; hydrostatic pump: PV axial piston Implement Flow 3.5 gpm 5.3 gpm Steering Flow 3.5 gpm 4.0 gpm Total Hydraulic Flow 7 gpm 9.3 gpm Overall Hydraulic Pump Flow 7 gpm 9.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Up to 2 (optional) ▶ Fluid CapacityFuel Tank Capacity 5.57 gal 7.5 gal Coolant Capacity Not Published 1.3 gal Crankcase Capacity Not Published 4.5 qt Transmission / Hydraulic System Capacity Not Published 5.5 gal Front Axle Fluid Capacity Not Published 1.0 gal ▶ PTO & HitchPTO Type Independent Not Published PTO Rear 540 rpm 540 rpm Mid-PTO Availability Standard, 2100 rpm Not Published Category, 3-Point Hitch Limited Category 1 Category 1 Hitch Lift Capacity Not Published 1,356 lb @ 24 in behind link arms Hitch Lift Capacity (at 24”) 758 lb 1356 lb Lift Control Type Select control Not Published ▶ Transmission & DrivetrainTransmission Type Hydrostatic - 2 range Hydrostatic transmission (HST) No. of Speeds Infinite (hydrostatic), 2 ranges forward and reverse Not Published Max Travel Speed (Forward) 9.1 mph Not Published Max Travel Speed (Reverse) 9.1 mph Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Foldable ROPS, standard equipment Open operator station (OOS) Steering Power steering Hydrostatic Brakes Wet disc, left-hand pedal Wet disc Seat Suspension & Adjustability Deluxe suspension seat with high back and adjustable settings; no tilt steering Not Published Front Axle Type Four-wheel drive (mechanical front-wheel drive) 4WD (MFWD) Front Axle Rating Not Published 1760 lb Drawbar Capacity Not Published 880 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch Not Published 115.9 in Overall Width 47.22 in (R3 tires); 47.32 in (R4 tires) 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) Wheelbase 57.1 in 62.8 in Ground Clearance Not Published 12.7 in (R4 tires) Min. Turn Radius without Brakes Not Published 9.4 ft (2.9 m) Height to Top of ROPS Not Published 95.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) Approx. 1,475 lb (shipping weight, open station) 2266 lb Weight with ROPS and Loader Not Published 2972 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf, R3 Hybrid, or R4 Industrial R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front Not Published 7-14 R1 Agricultural - Rear Not Published 11.2-24 R3 Turf - Front 18x8.50-10 27X8.50-15 R3 Turf - Rear 26x12-12 41X14-20 R4 Industrial - Front 18x8.5-10 25X8.50-14 or 27X8.50-15 R4 Industrial - Rear 26x12-12 15.00-19.5 or 43X16-20 ▶ Loader & AttachmentsQuick Attach Loader System Quik-Park Quick-change attachment carrier Loader Model 120R D160 Loader Lift Height 120R: 72 in 84 in Loader Lift Capacity (Full Height) 120R (NSL): 704 lb 1,186 lb Loader Breakout Force 1823 lbf (at pivot pin) 1,704 lb ▶ WarrantyWarranty Length & Coverage 6-Year / 2,000 Hour Limited Powertrain Warranty; standard at no cost, covers residential and commercial use 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
