▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNM74F-NCJT 3TNM74F Engine Type Diesel Yanmar EPA Tier 4 certified 3-cylinder, liquid cooled diesel (natural aspiration) No. of Cylinders 3 3 Displacement 60.6 in³ 60.6 in³ Rated Engine Speed 3200 rpm 3200 rpm Engine Power (Gross) 21.5 hp 21.5 hp PTO Power 16.2 hp 15.4 PTO HP Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Not Published Single Dry Fuel System Not Published Indirect Fuel Injection Alternator Not Published 40 A, 12 V ▶ HydraulicsPump Type Gear Single Gear Pump with Flow Divider Implement Flow 3.5 gpm 4.17 gpm Steering Flow 3.5 gpm 2.11 gpm Total Hydraulic Flow 7 gpm 6.97 gpm Overall Hydraulic Pump Flow 7 gpm 6.97 gpm Hydraulic System Type Open center Live, independent Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 5.57 gal 6.6 gal Coolant Capacity Not Published 3.7 qt Crankcase Capacity Not Published 2.1 qt Transmission / Hydraulic System Capacity Not Published 3.6 gal Front Axle Fluid Capacity Not Published 2.6 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Standard, 2100 rpm Optional (2,500 rpm) Category, 3-Point Hitch Limited Category 1 Category I Hitch Lift Capacity Not Published 1,100 lb Hitch Lift Capacity (at 24”) 758 lb 679 lb Lift Control Type Select control Position ▶ Transmission & DrivetrainTransmission Type Hydrostatic - 2 range Hydrostatic No. of Speeds Infinite (hydrostatic), 2 ranges forward and reverse 2 Range Max Travel Speed (Forward) 9.1 mph 7.8 mph Max Travel Speed (Reverse) 9.1 mph Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Differential lock ▶ Chassis, Steering & ControlsFrame Type Foldable ROPS, standard equipment Not Published Steering Power steering Hydrostatic Brakes Wet disc, left-hand pedal Wet Disc Seat Suspension & Adjustability Deluxe suspension seat with high back and adjustable settings; no tilt steering Suspension seat with armrests & retractable seat belt Front Axle Type Four-wheel drive (mechanical front-wheel drive) center-pivot, reverse Eliot type Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch Not Published 94.2 in Overall Width 47.22 in (R3 tires); 47.32 in (R4 tires) 44.5 in Wheelbase 57.1 in 53.1 in Ground Clearance Not Published F/A 8.3 in Min. Turn Radius without Brakes Not Published 86.6 in Height to Top of ROPS Not Published 86.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) Approx. 1,475 lb (shipping weight, open station) Not Published Weight with ROPS and Loader Not Published 1,942 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf, R3 Hybrid, or R4 Industrial R4 Industrial (Std), R3 Turf (Opt), Goodyear R14 (Opt) R1 Agricultural - Front Not Published BAR F 16X7.50-9 R1 Agricultural - Rear Not Published BAR R 24X12.00-12 R3 Turf - Front 18x8.50-10 16X7.50-8 R3 Turf - Rear 26x12-12 16X12.00-12 R4 Industrial - Front 18x8.5-10 Not Published R4 Industrial - Rear 26x12-12 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Quik-Park Skid-Steer Compatible Quick-Attach Loader Model 120R Not Published Loader Lift Height 120R: 72 in 72 in Loader Lift Capacity (Full Height) 120R (NSL): 704 lb 617 lb Loader Breakout Force 1823 lbf (at pivot pin) 1,285 lb ▶ WarrantyWarranty Length & Coverage 6-Year / 2,000 Hour Limited Powertrain Warranty; standard at no cost, covers residential and commercial use Full-machine: 24 months/2,000 hours; Powertrain: 96 months/3,000 hours (whichever comes first)
