▶ EnginePTO Power 18.2 hp 16.2 hp Alternator 40 A, 12 V 40 A Air Cleaner Dual element Dual element Engine Type Diesel Diesel Fuel System Indirect injection Indirect injection Displacement 77.3 in³ 60.6 in³ No. of Cylinders 3 3 Rated Engine Speed 3200 rpm 3200 rpm Cooling System Type Water pump (liquid-cooled) Water pump Engine Manufacturer Yanmar Yanmar Engine Power (Gross) 23.9 hp @ 200 rpm 21.5 hp @ 200 rpm Engine Emissions Constraints Tier 4 Tier 4 ▶ WeightWeight with ROPS and Loader ~2,005 lb (open station shipping weight 1,872 lb / 1,871.7 lb base; with H130 loader approx. 2,005 lb estimated) 1446 lb Weight with Cab and Loader ~2,392 lb base cab shipping weight (loader weight additive) — Tractor Weight (Base) — Open station: 1446 lb ▶ WarrantyWarranty Length & Coverage 2-year bumper-to-bumper (comprehensive) + 6-year/2,000-hour powertrain warranty 6-year powertrain warranty (as stated in 2016 review; current terms may vary) ▶ HydraulicsPump Type Gear Single gear Steering Flow 3.5 gpm 3.5 gpm Implement Flow 3.5 gpm 3.5 gpm Total Hydraulic Flow 5.6 gpm 21.2 lpm 6.3 gpm 23.8 lpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 3.4 gpm implement circuit; 7.0 gpm combined pump output 3.5 gpm (13.3 lpm) implement circuit Overall Hydraulic Pump Flow 3.4 gpm 12.9 lpm 6.3 gpm total (2.8 gpm steering + 3.5 gpm implement) No. of Optional Remote Valves 2 1 additional (optional 3rd SCV kit; standard is 2 mid-SCVs) No. of Standard Remote Valves 0 — System Operating Pressure — 2000 PSI ▶ PTO & HitchPTO Rear 540 rpm 540 rpm PTO Type independent independent Lift Control Type position control Position control (rockshaft lever) Hitch Lift Capacity 915 lb 1,433 lbs 1,433 lb Mid-PTO Availability Mid - 2100 rpm 2100 rpm Category, 3-Point Hitch Limited Category 1 Limited Category 1 Hitch Lift Capacity (at 24”) 915 lb 758 lb ▶ Tire OptionsR3 Turf - Rear 12-16.5 or R3 Radial: 280/70 R16 26x12-12 R3 Turf - Front 23x8.50-12 or R3 Radial: 220/55-R12 18x8.50-10 Tire Size & Options Front: 23x8.5-12 (R4 industrial / R3 turf); Rear: 31x12-16.5 (R4 industrial / R3 turf) — R4 Industrial - Rear 12-16.5 26x12-12 R4 Industrial - Front 23x8.50-12 18x8.5-10 R1 Agricultural - Rear Not separately listed; industrial R4 rear: 31x12.00-16.5 26x12-12 R1 Agricultural - Front Not separately listed; industrial R4 front: 23x8.50-12 18x8.5-10 ▶ Fluid CapacityCoolant Capacity 0.84 gal 0.98 gal Crankcase Capacity 0.84 gal 0.71 gal Fuel Tank Capacity 6.1 gal 5.6 gal Front Axle Fluid Capacity 0.89 gal 0.74 gal Transmission / Hydraulic System Capacity 3.5 gal 3.3 gal ▶ Loader & AttachmentsLoader Lift Height Gen 1 (H130): 78.9 in at pin; Gen 2 (120R): 72 in at pivot 71.2 in (D120 and H120 loaders) Loader Breakout Force Gen 1 (H130): 2,508 lb at pin; Gen 2 (120R): 1,963 lb at pivot — Quick Attach Loader System Quick-park / quick-attach system (H130 loader on Gen 1; 120R loader on Gen 2) Quik-Park Loader System Loader Lift Capacity (Full Height) Gen 1 (H130): 1,023 lb at pin; Gen 2 (120R): 754 lb at pivot D120: 570 lb; H120: 512 lb (at full height, 71.2 in) ▶ Transmission & DrivetrainClutch wet disc Wet disk No. of Speeds Two range (Hi and Lo) Infinite (hydrostatic, 2-range) Transmission Type Hydrostatic - two range Hydrostatic - two range Max Travel Speed (Forward) 12.3 mph 9.1 mph Max Travel Speed (Reverse) 11.4 mph 9.1 mph Differential Lock & Limited Slip Options Differential lock: Yes; Limited slip differential: No Differential lock Yes; Limited slip differential No ▶ Chassis, Steering & ControlsBrakes Wet disc Wet disc (left-hand pedal) Steering Power steering Power Frame Type Open center; spur gear final drive; wet disc brakes Open center frame with two-post foldable ROPS Front Axle Type Four-wheel drive MFWD (Mechanical Front-Wheel Drive) 4WD Drawbar Capacity Not Published — Front Axle Rating 1349 lb 1349 lb Seat Suspension & Adjustability Fore/aft adjustable; seat flips forward for weather protection; no mechanical suspension listed Spring suspension seat, adjusts fore/aft ▶ Dimensions & ManeuverabilityWheelbase 63 in. 57.1 in. Overall Width Not Published 47.2 in with R3 tires; 47.3 in with R4 tires Ground Clearance 12.5 in 7.7 in. Height to Top of ROPS Two-post foldable ROPS (folded/upright height not confirmed in sources) 78.6 in Height to Top of Cab Model Not Published — Height to Top of ROPS (folded) Not Published — Min. Turn Radius without Brakes 2.51 m 8.2 ft 2.51 m 8.2 ft Overall Length with 3-Point Hitch 109.2 in 87.6 in
