▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV80F-NCJT 3TNV80F-NCJT Engine Type Diesel Diesel No. of Cylinders 3 3 Displacement 77 in³ 77 in³ Rated Engine Speed 3200 rpm 3200 rpm Engine Power (Gross) 23.9 hp 23.2 hp PTO Power 17.2 hp 17.8 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Dual element Not Published Fuel System Indirect injection Not Published Alternator 40 A Not Published ▶ HydraulicsPump Type Not Published Gear Implement Flow 3.5 gpm 3.5 gpm Steering Flow 3.5 gpm 3.5 gpm Total Hydraulic Flow 7 gpm 7 gpm Overall Hydraulic Pump Flow 7 gpm 7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 3.5 gpm implement circuit; 7 gpm total capacity Not Published No. of Standard Remote Valves 2 Not Published No. of Optional Remote Valves Optional field kits: rear SCV kit (one set of hydraulic couplers at the rear); third mid-mounted SCV (additional set of mid-mount couplers) Not Published ▶ Fluid CapacityFuel Tank Capacity 6.1 gal 5.57 gal Coolant Capacity 0.81 gal Not Published Crankcase Capacity 0.84 gal Not Published Transmission / Hydraulic System Capacity 3.5 gal Not Published Front Axle Fluid Capacity 0.89 gal Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Standard; mid PTO 2100 rpm at 540 PTO marker Standard, 2100 rpm Category, 3-Point Hitch Limited Category 1 Limited Category I Hitch Lift Capacity 1,433 lb Not Published Hitch Lift Capacity (at 24”) 915 lb 758 lb Lift Control Type Position Control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic Hydrostatic - 2 range No. of Speeds Two range (Hi and Lo) Infinite (hydrostatic), 2 ranges forward and reverse Max Travel Speed (Forward) Not Published 9.1 mph Max Travel Speed (Reverse) Not Published 9.1 mph Clutch wet disc Not Published Differential Lock & Limited Slip Options Differential lock: Yes; Limited slip differential: No Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Foldable ROPS, standard equipment Steering Power Power steering Brakes Wet Disc Wet disc, left-hand pedal Seat Suspension & Adjustability Fore/aft adjustable; seat flips forward for weather protection; mechanical suspension not listed Suspension seat, high back, adjustable settings; tilt steering Front Axle Type Four-wheel drive Four-wheel drive Front Axle Rating 1,349 lb Not Published Drawbar Capacity 562 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 37 in (min); 51 in (max) 47.22 in (R3 tires); 47.32 in (R4 tires) Wheelbase 63 in 57.1 in Ground Clearance 13 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 89 in Not Published Height to Top of ROPS (folded) 66.8 in Not Published Height to Top of Cab Model Not Published Not Published Overall Length 109.2 in Not Published ▶ WeightTractor Weight (Base) 1,872 lb (with all fluids) 1,602 lb open station; 2,019 lb cab (shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: R3 Turf 23x8.50-12; R3 Radial 220/55-R12; R4 Industrial 23x8.50-12 R3 Turf, R3 Hybrid, or R4 R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front 23x8.50-12 or R3 Radial: 220/55-R12 18x8.50-10 R3 Turf - Rear 12-16.5 or R3 Radial: 280/70 R16 26x12-12 R4 Industrial - Front 23x8.50-12 18x8.5-10 R4 Industrial - Rear 12-16.5 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System H130 Loader (Quik-Park); 120R Loader (NSL standard, MSL optional, Quik-Park) Tool-free attach and park Loader Model 120R 120R Loader Lift Height 120R: 72 in (at pivot pin) 120R: 72 in Loader Lift Capacity (Full Height) 120R (NSL): 803 lb (at pivot pin, full height) 120R (NSL): 704 lb (at pivot, full height) Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours Powertrain 6 years or 2,000 hours, standard at no cost, covers residential and commercial use
