▶ EngineEngine Manufacturer Yanmar John Deere Engine Model 3TNV88C-NJT PowerTech 3029 (2.9L) EWR Engine Type Diesel Diesel, turbocharged No. of Cylinders 3 3 Displacement 95.8 in³ 179 in³ Rated Engine Speed 2500 rpm 2100 rpm Engine Power (Gross) 36.7 hp 73.7 hp PTO Power 30.4 hp PR/TSS OOS: 57 hp; PR/TSS Cab: 55 hp; eHydro: 51.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dual element Dry type with safety element Fuel System Direct injection Electronically controlled, high-pressure common rail Alternator 85 A 110 A ▶ HydraulicsPump Type Tandem gear PR/TSS: tandem gear pump (implement + steering); eHydro: three pumps Implement Flow 5.3 gpm 11.4 gpm Steering Flow 4 gpm 6.8 gpm Total Hydraulic Flow 9.3 gpm PR/TSS: 18.2 gpm; eHydro: 29.6 gpm Overall Hydraulic Pump Flow 9.3 gpm PR/TSS: 18.2 gpm; eHydro: 29.6 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published 11.4 gpm at a single rear SCV No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Up to 3 2 ▶ Fluid CapacityFuel Tank Capacity 8.5 gal OOS: 19 gal; Cab: 21 gal Coolant Capacity 5.5 qt Not Published Crankcase Capacity 4.5 qt 9.0 qt (with filter) Transmission / Hydraulic System Capacity 24.8 qt Not Published Front Axle Fluid Capacity 4 qt DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) Mid-PTO Availability 2000 rpm Not Published Category, 3-Point Hitch Category 1 Category II, convertible to I Hitch Lift Capacity Not Published 3,968 lb @ hitch points Hitch Lift Capacity (at 24”) 1,356 lb 3,192 lb Lift Control Type Position Control Position control, draft control, adjustable rate of drop ▶ Transmission & DrivetrainTransmission Type Hydrostatic SyncShuttle (standard); PowrReverser or eHydro (optional) No. of Speeds Infinite (2-range HST) 9F/3R (SyncShuttle); 12F/12R (PowrReverser) Max Travel Speed (Forward) 15.4 mph 15.5 mph (SyncShuttle) Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published SyncShuttle: dry; PowrReverser: wet; eHydro: hydrostatic Differential Lock & Limited Slip Options Differential lock: Yes Mechanical, rear ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power Hydrostatic power steering Brakes Wet Disc Hydraulically actuated wet disc brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Not Published Not Published Front Axle Type 4WD (MFWD) 2WD or MFWD Front Axle Rating 1,764 lb Not Published Drawbar Capacity Not Published Adjustable drawbar ▶ Dimensions & ManeuverabilityOverall Width 55.1 in Not Published Wheelbase 67.8 in 80.7 in Ground Clearance 9.8 in (front axle) 2WD: 18.8 in; MFWD: 13.4 in Min. Turn Radius without Brakes 98.4 in 11.5 ft (2WD); 15.3 ft (MFWD) Height to Top of ROPS 92.3 in (R4 tires) Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 117.5 in (with 3-point hitch) 144.5 in ▶ WeightTractor Weight (Base) 2,910 lb (with all fluids) OOS 2WD: 5,555 lb; OOS MFWD: 6,029 lb; Cab 2WD: 6,590 lb; Cab MFWD: 6,812 lb (shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Ag, R3 Turf, R4 Industrial, R3 Turf Radial Not Published R1 Agricultural - Front 7.00-12 MFWD: 11.2-24; 12.4-24 R1 Agricultural - Rear 12.4-16 16.9-28 R3 Turf - Front 23x8.50-14 Not Published R3 Turf - Rear 14-17.5 Not Published R4 Industrial - Front 23x8.50-14 Not Published R4 Industrial - Rear 14-17.5 Not Published ▶ Loader & AttachmentsQuick Attach Loader System 220R Loader (Quik-Park) 520M and H240 loaders (Loader Prep Package includes loader mounting frames and hood guard); not compatible with the 512 loader Loader Model 220R 500E, 500M or 520M Loader Lift Height 85 in (at pivot pin) 500M: 124 in Loader Lift Capacity (Full Height) 220R: 1,120 lb (at pivot pin, full height) 500M: 3,225 lb (at pivot, full height) Loader Breakout Force 1,949 lbf (at pivot pin) 500M: 4,354 lb (at pivot) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours Not Published
