▶ EngineEngine Manufacturer Yanmar Kubota Engine Model 3TNE74 D1703-M-DI-E4 / D1703-M-DI-E4K Engine Type 3-cylinder liquid-cooled diesel, indirect injection Direct injection, vertical, water-cooled 4-cycle, diesel No. of Cylinders 3 3 Displacement 61.4 in³ 100.5 in³ Rated Engine Speed 3000 rpm 2200 rpm Engine Power (Gross) 23 hp 23.3 hp PTO Power 17.7 hp 18.4 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry type with safety element Dry type, single element Fuel System Indirect injection, in-line fuel pump with solenoid shutoff Direct injection Alternator 20 A 40 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 3 gpm 5.2 gpm Steering Flow 2.5 gpm 3.1 gpm Total Hydraulic Flow 5.5 gpm 8.28 gpm (5.15 + 3.13, computed) Overall Hydraulic Pump Flow 5.5 gpm 8.28 gpm (5.15 + 3.13, computed) Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 5.0 gal 11.1 gal Coolant Capacity 3.2 qt 6.3 qt Crankcase Capacity 2.2 qt 6.0 qt Transmission / Hydraulic System Capacity 3.4 gal HST (4WD): 6.9 gal; DT (2WD): 7.4 gal; DT (4WD): 7.5 gal Front Axle Fluid Capacity 2.6 qt 4.8 qt ▶ PTO & HitchPTO Type Independent, wet disk clutch DT (2WD), DT (4WD): Transmission driven with overrunning clutch; HST (4WD): Live-independent hydraulic PTO with PTO brake, wet PTO Rear 540 rpm 540 rpm Mid-PTO Availability Standard, 2100 rpm Not Published Category, 3-Point Hitch Category 1 SAE Category I Hitch Lift Capacity Not Published 1874 lb Hitch Lift Capacity (at 24”) 701 lb 1389 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic DT (2WD), DT (4WD): Constant mesh with synchronized shuttle; HST (4WD): Hydrostatic transmission (3-range) No. of Speeds Infinite forward and reverse, 2 ranges DT (2WD), DT (4WD): 8 forward, 8 reverse; HST (4WD): 3-range Max Travel Speed (Forward) 8.4 mph DT (2WD), DT (4WD): 10.7 mph; HST (4WD): 11.5 mph Max Travel Speed (Reverse) 6.3 mph DT (2WD), DT (4WD): 10.7 mph; HST (4WD): 10.3 mph Clutch Not Published DT (2WD), DT (4WD): Dry type single stage; HST (4WD): Not Applicable Differential Lock & Limited Slip Options Not Published Rear differential lock, pedal operated ▶ Chassis, Steering & ControlsFrame Type Two-post fixed ROPS; four-wheel drive Not Published Steering Power steering Integral type power steering Brakes Wet disk Mechanical, wet disc type Seat Suspension & Adjustability Not Published Suspension seat with fore/aft travel adjustment and suspension tension adjustment Front Axle Type Mechanical front wheel drive (MFWD), standard, all ranges, engages on the go Cast-iron front axle Front Axle Rating 3120 lb Not Published Drawbar Capacity 562 lb 730 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 104.3 in DT (2WD): 110.6 in; DT (4WD), HST (4WD): 108.5 in (without 3-point hitch) Overall Width 47.2 in 55.1 in Wheelbase 57.1 in DT (2WD): 63.8 in; DT (4WD), HST (4WD): 63.4 in Ground Clearance 7.7 in (front axle) DT (2WD): 13.6 in; DT (4WD), HST (4WD): 13.4 in Min. Turn Radius without Brakes 88.6 in (MFWD off) DT (2WD): 7.9 ft; DT (4WD), HST (4WD): 8.2 ft (with brake applied) Height to Top of ROPS 77.6 in 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1400 lb DT (2WD): 2601 lb; DT (4WD): 2811 lb; HST (4WD): 2833 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 18x8.5-10 front and 26x12.00-12 rear; R1 standard, R3 optional R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 18x8.5-10 DT (2WD): 5.0-15; DT (4WD), HST (4WD): 7.2-16 R1 Agricultural - Rear 26x12.00-12 11.2-24 R3 Turf - Front 18x8.5-10 DT (2WD): 23X8.50-12; DT (4WD), HST (4WD): 25X8.50-14 R3 Turf - Rear 26x12.00-12 13.6-16 R4 Industrial - Front 18x8.50-10 DT (2WD): Not Applicable; DT (4WD), HST (4WD): 27X8.50-15 R4 Industrial - Rear 26x12.00-12 DT (2WD): Not Applicable; DT (4WD), HST (4WD): 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) Loader Model 210 LA526 Loader Lift Height 210: 68.5 in LA526: 94.8 in Loader Lift Capacity (Full Height) 210: 622 lb (to max height at pivot point) LA526: 1,096 lb Loader Breakout Force 210: 1577 lbf (at pivot point) Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
