▶ EngineEngine Manufacturer Yanmar Mitsubishi Engine Model 3TNE74 MVL3E3 Engine Type 3-cylinder liquid-cooled diesel, indirect injection Four Stroke, Naturally Aspired, Indirect Injection, Water-Cooled Diesel Engine No. of Cylinders 3 3 Displacement 61.4 in³ 67.2 in³ Rated Engine Speed 3000 rpm 3000 rpm Engine Power (Gross) 23 hp 22.9 hp PTO Power 17.7 hp 16.8 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Water-Cooled Air Cleaner Dry type with safety element Not Published Fuel System Indirect injection, in-line fuel pump with solenoid shutoff Indirect Injection Alternator 20 A 55 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 3 gpm 7.6 gpm Steering Flow 2.5 gpm 3.8 gpm Total Hydraulic Flow 5.5 gpm 11.2 gpm Overall Hydraulic Pump Flow 5.5 gpm 11.2 gpm Hydraulic System Type Not Published Open Center, full-live hydraulic with position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Single or dual ▶ Fluid CapacityFuel Tank Capacity 5.0 gal 6.6 gal Coolant Capacity 3.2 qt Not Published Crankcase Capacity 2.2 qt Not Published Transmission / Hydraulic System Capacity 3.4 gal Not Published Front Axle Fluid Capacity 2.6 qt Not Published ▶ PTO & HitchPTO Type Independent, wet disk clutch Independent Wet Clutch PTO Rear 540 rpm 540 rpm @ 2837 rpm Mid-PTO Availability Standard, 2100 rpm Optional; 2500 rpm @ 2837 rpm Category, 3-Point Hitch Category 1 CAT I with check chains Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 701 lb 771 lb Lift Control Type Not Published Position Control ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic HST - 2 Range No. of Speeds Infinite forward and reverse, 2 ranges Infinite forward and reverse (2 ranges) Max Travel Speed (Forward) 8.4 mph 7.3 mph Max Travel Speed (Reverse) 6.3 mph Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Two-post fixed ROPS; four-wheel drive Not Published Steering Power steering Hydrostatic Power Steering Brakes Wet disk Single Pedal Seat Suspension & Adjustability Not Published Not Published Front Axle Type Mechanical front wheel drive (MFWD), standard, all ranges, engages on the go Not Published Front Axle Rating 3120 lb Not Published Drawbar Capacity 562 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 104.3 in 100.4 in Overall Width 47.2 in 46.3 in Wheelbase 57.1 in 55.1 in Ground Clearance 7.7 in (front axle) 6.7 in Min. Turn Radius without Brakes 88.6 in (MFWD off) 7.2 ft (with brake applied) Height to Top of ROPS 77.6 in 86.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1400 lb 1620 lb Weight with ROPS and Loader Not Published 2026 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 18x8.5-10 front and 26x12.00-12 rear; R1 standard, R3 optional R3 Turf, R4 Industrial R1 Agricultural - Front 18x8.5-10 Not Published R1 Agricultural - Rear 26x12.00-12 Not Published R3 Turf - Front 18x8.5-10 18x8.5-10 R3 Turf - Rear 26x12.00-12 26x12-12 R4 Industrial - Front 18x8.50-10 18x8.5-10 R4 Industrial - Rear 26x12.00-12 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System Not Published L11: Front loader skid-steer couplers for superfast hookups Loader Model 210 L11 Loader Lift Height 210: 68.5 in L11: 68 in Loader Lift Capacity (Full Height) 210: 622 lb (to max height at pivot point) L11: 794 lb Loader Breakout Force 210: 1577 lbf (at pivot point) L11: 1433 lb ▶ WarrantyWarranty Length & Coverage Not Published 7-Year Limited Powertrain Warranty
