▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV82A-BMJK 3TNV80F-NCJT Engine Type 3-cylinder liquid-cooled diesel Diesel No. of Cylinders 3 3 Displacement 81.2 in³ 77 in³ Rated Engine Speed 2600 rpm 3200 rpm Engine Power (Gross) 26.5 hp 23.9 hp PTO Power 20.5 hp 17.2 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Water pump (liquid-cooled) Air Cleaner Dry type, two stage Dual element Fuel System Not Published Indirect injection Alternator 20 A 40 A, 12 V ▶ HydraulicsPump Type Not Published Gear Implement Flow 5.0 gpm 3.5 gpm Steering Flow 5.5 gpm 3.5 gpm Total Hydraulic Flow 10.5 gpm 7 gpm Overall Hydraulic Pump Flow 10.5 gpm 7 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published 3.4 gpm implement circuit; 7.0 gpm combined pump output No. of Standard Remote Valves 2 0 No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 7.1 gal 6.1 gal Coolant Capacity 4.1 qt 0.84 gal Crankcase Capacity 3.0 qt 0.84 gal Transmission / Hydraulic System Capacity 3.9 gal 3.5 gal Front Axle Fluid Capacity 3.6 qt 0.89 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm (rear PTO standard) 540 rpm Mid-PTO Availability Standard 2000 rpm Category, 3-Point Hitch Category 1 Limited Category I Hitch Lift Capacity 1433 lb 1433 lb Hitch Lift Capacity (at 24”) 1150 lb 915 lb Lift Control Type Position control Position Control ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic Hydrostatic No. of Speeds Infinite forward and reverse, 2 ranges Two range (Hi and Lo) Max Travel Speed (Forward) 13.0 mph 12.3 mph Max Travel Speed (Reverse) 13.0 mph 11.4 mph Clutch Not Published wet disc Differential Lock & Limited Slip Options Not Published Differential lock: Yes; Limited slip differential: No ▶ Chassis, Steering & ControlsFrame Type Folding ROPS standard Open center; spur gear final drive; wet disc brakes Steering Power steering Power Brakes Wet disk Wet Disc Seat Suspension & Adjustability Not Published Fore/aft adjustable; seat flips forward for weather protection; no mechanical suspension listed Front Axle Type Mechanical front wheel drive (MFWD), standard, all ranges, engages on the go Four-wheel drive Front Axle Rating 1940 lb 1940 lb Drawbar Capacity Not Published 562 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 108.9 in 109.2 in Overall Width 51.0 in (minimum, standard tires) 37 in (min); 51 in (max) Wheelbase 65.2 in 63 in Ground Clearance 13 in (front axle); 11 in (rear axle drawbar) 12.5 in Min. Turn Radius without Brakes 8.2 ft 2.51 m 8.2 ft Height to Top of ROPS 90 in 89 in Height to Top of ROPS (folded) 68.9 in 66.8 in Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1865 lb 1660 lb Weight with ROPS and Loader Not Published ~2,005 lb (open station shipping weight 1,872 lb / 1,871.7 lb base; with H130 loader approx. 2,005 lb estimated) Weight with Cab and Loader Not Published ~2,392 lb base cab shipping weight (loader weight additive) ▶ Tire OptionsTire Size & Options R3 turf standard (24x8.5-14 front, 36x14.00-15 rear); R4 industrial optional (23x8.5-12 front, 14-17.5 rear) Front: 23x8.5-12 (R4 industrial / R3 turf); Rear: 31x12-16.5 (R4 industrial / R3 turf) R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front 24x8.5-14 23x8.50-12 or R3 Radial: 220/55-R12 R3 Turf - Rear 36x14.00-15 12-16.5 or R3 Radial: 280/70 R16 R4 Industrial - Front 23x8.5-12 23x8.50-12 R4 Industrial - Rear 14-17.5 31x12.00-16.5 ▶ Loader & AttachmentsQuick Attach Loader System Quik-Park loader mounting; 200CX attaches and detaches in under 3 minutes with no tools H130 Loader (Quik-Park); 120R Loader (NSL standard, MSL optional, Quik-Park) Loader Model 200CX H130 or 120R Loader Lift Height 200CX: 78.5 in H130: 78.9 in; 120R: 72 in (at pivot pin) Loader Lift Capacity (Full Height) 200CX: 800 lb (at full height, measured at pivot) H130: 1,023 lb; 120R (NSL): 803 lb (at pivot pin, full height) Loader Breakout Force 200CX: 2239 lbf (at pin) H130: 2,508 lbf (at pivot pin); 120R: Not Published ▶ WarrantyWarranty Length & Coverage 3-year / 2,000-hour limited warranty (as sold new) 2-year bumper-to-bumper (comprehensive) + 6-year/2,000-hour powertrain warranty
