▶ EngineEngine Manufacturer Yanmar Mitsubishi Engine Model 3TNV82A-BMJK Not Published Engine Type 3-cylinder liquid-cooled diesel Three cylinder, four cycle, valve in cylinder head, cross flow porting diesel No. of Cylinders 3 3 Displacement 81.2 in³ 80.43 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 26.5 hp 26 hp PTO Power 20.5 hp 23 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Liquid-cooled, pressurized, thermostat controlled bypass, impeller pump Air Cleaner Dry type, two stage Dry type with double filter Fuel System Not Published Indirect injection; Bosch M type ND-PFR (Denso) injection pump, throttle type injectors Alternator 20 A 50 A ▶ HydraulicsPump Type Not Published Gear type, front mounted, engine driven Implement Flow 5.0 gpm 7.8 gpm Steering Flow 5.5 gpm 3.4 gpm Total Hydraulic Flow 10.5 gpm 11.2 gpm (7.8 + 3.4, computed) Overall Hydraulic Pump Flow 10.5 gpm Not Published Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Not Published No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 7.1 gal Not Published Coolant Capacity 4.1 qt Not Published Crankcase Capacity 3.0 qt Not Published Transmission / Hydraulic System Capacity 3.9 gal Not Published Front Axle Fluid Capacity 3.6 qt Not Published ▶ PTO & HitchPTO Type Independent Independent (3016 Gear Drive); Live (3016 Hydrostatic Drive) PTO Rear 540 rpm (rear PTO standard) 540 rpm @ 2376 rpm Mid-PTO Availability Standard Optional; 2000 rpm @ 2525 rpm Category, 3-Point Hitch Category 1 CAT I Hitch Lift Capacity 1433 lb Not Published Hitch Lift Capacity (at 24”) 1150 lb 1720 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic Synchro shuttle, constant mesh main with 2 ranges (3016 Gear Drive); Hydrostatic, 3 ranges (3016 Hydrostatic Drive) No. of Speeds Infinite forward and reverse, 2 ranges 8F/8R (3016 Gear Drive); Infinite, 3 ranges (3016 Hydrostatic Drive) Max Travel Speed (Forward) 13.0 mph 11.9 mph (3016 Gear Drive); 13.8 mph (3016 Hydrostatic Drive) Max Travel Speed (Reverse) 13.0 mph 9.9 mph (3016 Gear Drive); 6.9 mph (3016 Hydrostatic Drive) Clutch Not Published Dry single disc, diaphragm type, 8.46 in Differential Lock & Limited Slip Options Not Published Mechanical differential lock, pedal actuated ▶ Chassis, Steering & ControlsFrame Type Folding ROPS standard Not Published Steering Power steering Hydrostatic power steering Brakes Wet disk Wet disc, mechanical Seat Suspension & Adjustability Not Published Not Published Front Axle Type Mechanical front wheel drive (MFWD), standard, all ranges, engages on the go Mechanical front drive (MFD), spiral bevel gear differential with bevel gear reductions Front Axle Rating 1940 lb Not Published Drawbar Capacity Not Published 969 lbf ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 108.9 in 121.3 in Overall Width 51.0 in (minimum, standard tires) 63 in Wheelbase 65.2 in 67.3 in Ground Clearance 13 in (front axle); 11 in (rear axle drawbar) 11.4 in Min. Turn Radius without Brakes 8.2 ft 7.9 ft (with brake applied) Height to Top of ROPS 90 in 81.5 in Height to Top of ROPS (folded) 68.9 in Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1865 lb 2437 lb (3016 Gear Drive); 2459 lb (3016 Hydrostatic Drive) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 turf standard (24x8.5-14 front, 36x14.00-15 rear); R4 industrial optional (23x8.5-12 front, 14-17.5 rear) Not Published R1 Agricultural - Front Not Published 7x16 R1 Agricultural - Rear Not Published 11.2x24 R3 Turf - Front 24x8.5-14 25x8.5-14 R3 Turf - Rear 36x14.00-15 13.6x16 R4 Industrial - Front 23x8.5-12 27x8.50-15 R4 Industrial - Rear 14-17.5 15x19.5 ▶ Loader & AttachmentsQuick Attach Loader System Quik-Park loader mounting; 200CX attaches and detaches in under 3 minutes with no tools Not Published Loader Model 200CX ML115 Loader Lift Height 200CX: 78.5 in ML115: 99 in Loader Lift Capacity (Full Height) 200CX: 800 lb (at full height, measured at pivot) ML115: 1,650 lb Loader Breakout Force 200CX: 2239 lbf (at pin) ML115: 2,650 lb ▶ WarrantyWarranty Length & Coverage 3-year / 2,000-hour limited warranty (as sold new) Not Published
