▶ EngineEngine Manufacturer Yanmar Mitsubishi Engine Model 3TNV88F-EPJPT Not Published Engine Type 4-cycle, inline, water-cooled diesel, naturally aspirated 3-cylinder, turbocharged & aftercooled, Tier 4 B/Final No. of Cylinders 3 3 Displacement 100.2 in³ 80.4 in³ Rated Engine Speed 2400 rpm 2500 rpm Engine Power (Gross) 24.4 hp 24.4 hp PTO Power 20.7 hp 17.1 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid Liquid-cooled Air Cleaner Dry Not Published Fuel System Direct injection Not Published Alternator 55 A, 12 V Not Published ▶ HydraulicsPump Type 2 single-section external gear pumps, 1 on each side of the engine timing-gear cover Not Published Implement Flow 5.1 gpm 7.9 gpm Steering Flow 3.8 gpm Not Published Total Hydraulic Flow 8.5 gpm Not Published Overall Hydraulic Pump Flow 8.9 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None 0 No. of Optional Remote Valves Up to two (optional) 1 ▶ Fluid CapacityFuel Tank Capacity 9.7 gal 7.4 gal Coolant Capacity 1.18 gal Not Published Crankcase Capacity 1.1 gal Not Published Transmission / Hydraulic System Capacity 9.24 gal Not Published Front Axle Fluid Capacity 1.0 gal Not Published ▶ PTO & HitchPTO Type Not Published Independent PTO Rear 540 rpm at 2400 rpm engine (rated) 540 rpm Mid-PTO Availability Not Published Optional, 2,000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 1,670 lb 1,433 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type 8F/8R gear drive transmission Hydrostatic (optional) No. of Speeds 8F/8R Infinite (hydrostatic) Max Travel Speed (Forward) 11.1 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Not Published Not Published Seat Suspension & Adjustability Not Published Not Published Front Axle Type MFWD (4WD) Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity 1,102 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 57.3 in Not Published Wheelbase 62 in 65.9 in Ground Clearance 14 in Not Published Min. Turn Radius without Brakes 6.9 ft (with brake applied) Not Published Height to Top of ROPS Not Published 88.2 in Height to Top of ROPS (folded) Not Published 68.2 in Height to Top of Cab Model Not Published Not Published Overall Length 111.2 in 117.2 in ▶ WeightTractor Weight (Base) 2,778 lb 2,469 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial Not Published R1 Agricultural - Front 7-14 Not Published R1 Agricultural - Rear 11.2-24 Not Published R3 Turf - Front 27X8.50-15 Not Published R3 Turf - Rear 41X14-20 Not Published R4 Industrial - Front 25X8.50-14 Not Published R4 Industrial - Rear 15-19.5 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Quick-change attachment carrier Not Published Loader Model 300E L330 Loader Lift Height 84.0 in (at pivot pin) 94.3 in Loader Lift Capacity (Full Height) 1,186 lb (at pivot pin) 1,214 lb Loader Breakout Force 1,704 lb (at pivot pin) 1,926 lb ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours Basic 2 years; powertrain 4 additional years (6-year total)
