▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV88F-EPJPT 3TNV80F-NCJT Engine Type 4-cycle, inline, water-cooled diesel, naturally aspirated Diesel No. of Cylinders 3 3 Displacement 100.2 in³ 77 in³ Rated Engine Speed 2400 rpm 3200 rpm Engine Power (Gross) 24.4 hp 23.9 hp PTO Power 20.7 hp 17.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid Liquid cooled Air Cleaner Dry Dual element Fuel System Direct injection Indirect injection Alternator 55 A, 12 V 40 A ▶ HydraulicsPump Type 2 single-section external gear pumps, 1 on each side of the engine timing-gear cover Not Published Implement Flow 5.1 gpm 3.5 gpm Steering Flow 3.8 gpm 3.5 gpm Total Hydraulic Flow 8.5 gpm 7 gpm Overall Hydraulic Pump Flow 8.9 gpm 7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 3.5 gpm implement circuit; 7 gpm total capacity No. of Standard Remote Valves None 2 No. of Optional Remote Valves Up to two (optional) Optional field kits: rear SCV kit (one set of hydraulic couplers at the rear); third mid-mounted SCV (additional set of mid-mount couplers) ▶ Fluid CapacityFuel Tank Capacity 9.7 gal 6.1 gal Coolant Capacity 1.18 gal 0.81 gal Crankcase Capacity 1.1 gal 0.84 gal Transmission / Hydraulic System Capacity 9.24 gal 3.5 gal Front Axle Fluid Capacity 1.0 gal 0.89 gal ▶ PTO & HitchPTO Type Not Published Independent PTO Rear 540 rpm at 2400 rpm engine (rated) 540 rpm Mid-PTO Availability Not Published Standard; mid PTO 2100 rpm at 540 PTO marker Category, 3-Point Hitch Category I Limited Category 1 Hitch Lift Capacity Not Published 1,433 lb Hitch Lift Capacity (at 24”) 1,670 lb 915 lb Lift Control Type Position control Position Control ▶ Transmission & DrivetrainTransmission Type 8F/8R gear drive transmission Hydrostatic No. of Speeds 8F/8R Two range (Hi and Lo) Max Travel Speed (Forward) 11.1 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published wet disc Differential Lock & Limited Slip Options Not Published Differential lock: Yes; Limited slip differential: No ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power Brakes Not Published Wet Disc Seat Suspension & Adjustability Not Published Fore/aft adjustable; seat flips forward for weather protection; mechanical suspension not listed Front Axle Type MFWD (4WD) Four-wheel drive Front Axle Rating Not Published 1,349 lb Drawbar Capacity 1,102 lb 562 lb ▶ Dimensions & ManeuverabilityOverall Width 57.3 in 37 in (min); 51 in (max) Wheelbase 62 in 63 in Ground Clearance 14 in 13 in Min. Turn Radius without Brakes 6.9 ft (with brake applied) Not Published Height to Top of ROPS Not Published 89 in Height to Top of ROPS (folded) Not Published 66.8 in Height to Top of Cab Model Not Published Not Published Overall Length 111.2 in 109.2 in ▶ WeightTractor Weight (Base) 2,778 lb 1,872 lb (with all fluids) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial Front: R3 Turf 23x8.50-12; R3 Radial 220/55-R12; R4 Industrial 23x8.50-12 R1 Agricultural - Front 7-14 Not Published R1 Agricultural - Rear 11.2-24 Not Published R3 Turf - Front 27X8.50-15 23x8.50-12 or R3 Radial: 220/55-R12 R3 Turf - Rear 41X14-20 12-16.5 or R3 Radial: 280/70 R16 R4 Industrial - Front 25X8.50-14 23x8.50-12 R4 Industrial - Rear 15-19.5 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System Quick-change attachment carrier H130 Loader (Quik-Park); 120R Loader (NSL standard, MSL optional, Quik-Park) Loader Model 300E 120R Loader Lift Height 84.0 in (at pivot pin) 120R: 72 in (at pivot pin) Loader Lift Capacity (Full Height) 1,186 lb (at pivot pin) 120R (NSL): 803 lb (at pivot pin, full height) Loader Breakout Force 1,704 lb (at pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours
