▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV88F-EPJPT 3TNE74 Engine Type 4-cycle, inline, water-cooled diesel, naturally aspirated 3-cylinder liquid-cooled diesel, indirect injection No. of Cylinders 3 3 Displacement 100.2 in³ 61.4 in³ Rated Engine Speed 2400 rpm 3000 rpm Engine Power (Gross) 24.4 hp 23 hp PTO Power 20.7 hp 17.7 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid Liquid-cooled Air Cleaner Dry Dry type with safety element Fuel System Direct injection Indirect injection, in-line fuel pump with solenoid shutoff Alternator 55 A, 12 V 20 A ▶ HydraulicsPump Type 2 single-section external gear pumps, 1 on each side of the engine timing-gear cover Not Published Implement Flow 5.1 gpm 3 gpm Steering Flow 3.8 gpm 2.5 gpm Total Hydraulic Flow 8.5 gpm 5.5 gpm Overall Hydraulic Pump Flow 8.9 gpm 5.5 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None Not Published No. of Optional Remote Valves Up to two (optional) Not Published ▶ Fluid CapacityFuel Tank Capacity 9.7 gal 5.0 gal Coolant Capacity 1.18 gal 3.2 qt Crankcase Capacity 1.1 gal 2.2 qt Transmission / Hydraulic System Capacity 9.24 gal 3.4 gal Front Axle Fluid Capacity 1.0 gal 2.6 qt ▶ PTO & HitchPTO Type Not Published Independent, wet disk clutch PTO Rear 540 rpm at 2400 rpm engine (rated) 540 rpm Mid-PTO Availability Not Published Standard, 2100 rpm Category, 3-Point Hitch Category I Category 1 Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 1,670 lb 701 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type 8F/8R gear drive transmission 2-range hydrostatic No. of Speeds 8F/8R Infinite forward and reverse, 2 ranges Max Travel Speed (Forward) 11.1 mph 8.4 mph Max Travel Speed (Reverse) Not Published 6.3 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post fixed ROPS; four-wheel drive Steering Power steering Power steering Brakes Not Published Wet disk Seat Suspension & Adjustability Not Published Not Published Front Axle Type MFWD (4WD) MFWD, standard, all ranges, on-the-go engagement Front Axle Rating Not Published 3,120 lb Drawbar Capacity 1,102 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 57.3 in 47.2 in Wheelbase 62 in 57.1 in Ground Clearance 14 in 7.7 in (front axle) Min. Turn Radius without Brakes 6.9 ft (with brake applied) 88.6 in (MFWD off) Height to Top of ROPS Not Published 77.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 111.2 in 104.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,778 lb 1,400 lb (with all fluids) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial 18x8.5-10 front and 26x12.00-12 rear; R1 standard, R3 optional R1 Agricultural - Front 7-14 18x8.5-10 R1 Agricultural - Rear 11.2-24 26x12.00-12 R3 Turf - Front 27X8.50-15 18x8.5-10 R3 Turf - Rear 41X14-20 26x12.00-12 R4 Industrial - Front 25X8.50-14 18x8.50-10 R4 Industrial - Rear 15-19.5 26x12.00-12 ▶ Loader & AttachmentsQuick Attach Loader System Quick-change attachment carrier Not Published Loader Model 300E 210 Loader Lift Height 84.0 in (at pivot pin) 210: 68.5 in (at pivot pin) Loader Lift Capacity (Full Height) 1,186 lb (at pivot pin) 210: 622 lb (to max height at pivot point) Loader Breakout Force 1,704 lb (at pivot pin) 210: 1,577 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours Not Published
