▶ EngineEngine Manufacturer Yanmar Mitsubishi Engine Model 3TNV88F-EPJT S3L2 Engine Type 4-cycle, inline, water-cooled diesel, naturally aspirated Four stroke, indirect injection water-cooled diesel No. of Cylinders 3 3 Displacement 100.1 in³ 80.4 in³ Rated Engine Speed 2400 rpm 2500 rpm Engine Power (Gross) 24.4 hp 24.4 hp PTO Power 20.7 hp 19.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid Water-cooled Air Cleaner Dual element Not Published Fuel System Direct injection Indirect Injection Alternator 55 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Two single-section external gear pumps, one each side of engine timing-gear cover Not Published Implement Flow 4.8 gpm 4.6 gpm Steering Flow 3.6 gpm 2.7 gpm Total Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 8.9 gpm Not Published Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to two (optional) 1 ▶ Fluid CapacityFuel Tank Capacity 10.0 gal 6.1 gal Coolant Capacity 1.2 gal Not Published Crankcase Capacity 1.1 gal Not Published Transmission / Hydraulic System Capacity 9.2 gal Not Published Front Axle Fluid Capacity 1.0 gal Not Published ▶ PTO & HitchPTO Type Not Published Live PTO Rear 540 rpm at 2400 rpm engine (rated) 540 @ 2376 rpm Mid-PTO Availability Not Published Available; 2000 @ 2556 rpm Category, 3-Point Hitch Category I Category I, with check chains Hitch Lift Capacity Not Published 1400 lb Hitch Lift Capacity (at 24”) 2,081.2 lb @ 24 in behind link arms Not Published Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type 8F/8R synchromesh shuttle shift gear transmission HST - 2 ranges No. of Speeds 8F/8R Infinite Max Travel Speed (Forward) 11.1 mph 9.6 mph Max Travel Speed (Reverse) 11.6 mph 4.9 mph Clutch Not Published Single plate, dry Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Not Published Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type MFWD (4WD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1102 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 111.2 in 104.1 in Overall Width 57.3 in 50.7 in Wheelbase 62.6 in Not Published Ground Clearance 13.0 in Not Published Min. Turn Radius without Brakes 6.9 ft (with brakes) (with brake applied) 7.2 ft Height to Top of ROPS Not Published 81.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2987 lb 1693 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial Not Published R1 Agricultural - Front 7-14 6x12 R1 Agricultural - Rear 11.2-24 9.5x16 R3 Turf - Front 27X8.50-15 20x8-10 R3 Turf - Rear 41X14-20 29x12.5-15 R4 Industrial - Front 25X8.50-14 20x8-10 R4 Industrial - Rear 15.00-19.5 27x12.5-15 ▶ Loader & AttachmentsQuick Attach Loader System Quick-change attachment carrier Not Published Loader Model D160 Max 24L Loader Lift Height 84.0 in Max 24L: 75 in Loader Lift Capacity (Full Height) 1,186 lb Max 24L: 900 lb (at pivot pin) Loader Breakout Force 1,704 lb Max 24L: 2000 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) Two Year All Aggregate (bumper to bumper) plus Five-Year Limited Powertrain; extends to a total 7-year / 3000 Hrs Limited Powertrain on eligible non-commercial, residential purchases
