▶ EngineEngine Manufacturer Yanmar TYM Engine Model 3TNV88F-EPJT2 A1700N6-BUTR_3 Engine Type Diesel, naturally aspirated, direct injection Vertical, 4-stroke, water-cooled diesel No. of Cylinders 3 3 Displacement 95.7 in³ 104.7 in³ Rated Engine Speed 2400 rpm 2100 rpm Engine Power (Gross) 24.4 hp 24.5 hp PTO Power 17.4 hp 19.1 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water pump Water-cooled Air Cleaner Dry type with safety element Dry Fuel System Direct injection Not Published Alternator 55 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Implement/steering pump: Tandem gear; hydrostatic pump: PV axial piston Gear type (primary 0.8 in³/rev, secondary 0.4 in³/rev) Implement Flow 5.3 gpm 7.5 gpm Steering Flow 4.0 gpm 4 gpm Total Hydraulic Flow 9.3 gpm 11.5 gpm Overall Hydraulic Pump Flow 9.3 gpm 11.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 2 (optional) 2 ▶ Fluid CapacityFuel Tank Capacity 7.5 gal 7.13 gal Coolant Capacity 1.3 gal 1.32 gal Crankcase Capacity 4.5 qt 1.14 gal Transmission / Hydraulic System Capacity 5.5 gal Manual: 8.98 gal; HST: 9.77 gal Front Axle Fluid Capacity 1.0 gal Not Published ▶ PTO & HitchPTO Type Not Published Independent PTO Rear 540 rpm 533 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,356 lb @ 24 in behind link arms 3,306.9 lb Hitch Lift Capacity (at 24”) 1356 lb 2,425 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (HST) Hydrostatic (HST) No. of Speeds Not Published 3 range (A/B/C) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published None (HST) Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Open operator station (OOS) Heavy-duty steel frame with cast iron axles Steering Hydrostatic Fully hydraulic power steering Brakes Wet disc Wet multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type 4WD (MFWD) Selectable 4WD Front Axle Rating 1760 lb Not Published Drawbar Capacity 880 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 115.9 in 134.88 in Overall Width 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) 56.7 in Wheelbase 62.8 in 65.7 in Ground Clearance 12.7 in (R4 tires) 15 in Min. Turn Radius without Brakes 9.4 ft (2.9 m) Not Published Height to Top of ROPS 95.3 in 96.85 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2266 lb 2,969.6 lb Weight with ROPS and Loader 2972 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial R1 Agricultural (8.0-16 / 12.4-24 standard), R4 Industrial (25x8.50-14 / 15-19.5) R1 Agricultural - Front 7-14 8.0-16 R1 Agricultural - Rear 11.2-24 12.4-24 R3 Turf - Front 27X8.50-15 Not Published R3 Turf - Rear 41X14-20 Not Published R4 Industrial - Front 25X8.50-14 or 27X8.50-15 25x8.50-14 R4 Industrial - Rear 15.00-19.5 or 43X16-20 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Quick-change attachment carrier Quick attach front loader Loader Model D160 BBL400 Loader Lift Height 84 in 104 in Loader Lift Capacity (Full Height) 1,186 lb 2,200 lb Loader Breakout Force 1,704 lb 3,660 lbf ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) Engine and powertrain: 72 months or 2,000 hours; other tractor parts: 24 months or 1,000 hours; loader and backhoe: 24 months from shipment, 12 months from sale, or 500 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
