▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV88F-EPJT2 3TNV80F-CJT Engine Type Diesel, naturally aspirated, direct injection 3-cylinder, liquid-cooled diesel No. of Cylinders 3 3 Displacement 95.7 in³ 77.3 in³ Rated Engine Speed 2400 rpm 3200 rpm Engine Power (Gross) 24.4 hp 23.9 hp PTO Power 17.4 hp 18 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water pump Liquid-cooled Air Cleaner Dry type with safety element Dry with safety element Fuel System Direct injection Indirect injection Alternator 55 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Implement/steering pump: Tandem gear; hydrostatic pump: PV axial piston Gear Implement Flow 5.3 gpm 3.3 gpm Steering Flow 4.0 gpm 3.3 gpm Total Hydraulic Flow 9.3 gpm 6.5 gpm Overall Hydraulic Pump Flow 9.3 gpm 6.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 3.5 gpm per pump (implement circuit); total system output 6.3 gpm No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 2 (optional) Three ▶ Fluid CapacityFuel Tank Capacity 7.5 gal 5.6 gal Coolant Capacity 1.3 gal 3.9 qt Crankcase Capacity 4.5 qt 2.9 qt Transmission / Hydraulic System Capacity 5.5 gal 3.25 gal Front Axle Fluid Capacity 1.0 gal 3.0 qt ▶ PTO & HitchPTO Type Not Published Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Standard, 2100 rpm Category, 3-Point Hitch Category I Limited Category I Hitch Lift Capacity 1,356 lb @ 24 in behind link arms 1177 lb Hitch Lift Capacity (at 24”) 1356 lb 758 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (HST) Hydrostatic - 2 range No. of Speeds Not Published Infinite (hydrostatic), 2 ranges forward and reverse Max Travel Speed (Forward) Not Published 9.1 mph Max Travel Speed (Reverse) Not Published 9.1 mph Clutch Not Published wet disc Differential Lock & Limited Slip Options Not Published Standard rear differential lock ▶ Chassis, Steering & ControlsFrame Type Open operator station (OOS) Semi-flat platform; two-post folding ROPS; 4WD with mechanical front-wheel drive Steering Hydrostatic Power steering Brakes Wet disc Wet disk, left-hand pedal Seat Suspension & Adjustability Not Published Premium seat; adjusts fore/aft; seat flips forward; high seat back and armrests; retractable seat belt Front Axle Type 4WD (MFWD) Four-wheel drive (mechanical front-wheel drive, on-the-go engagement) Front Axle Rating 1760 lb 1349 lb Drawbar Capacity 880 lb 2165 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 115.9 in 108 in Overall Width 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) 47.22 in (R3 tires); 47.32 in (R4 tires) Wheelbase 62.8 in 57.1 in Ground Clearance 12.7 in (R4 tires) 9.0 in under the front axle (operator's manual); 7.7 in (Deere website) Min. Turn Radius without Brakes 9.4 ft (2.9 m) 88.8 in Height to Top of ROPS 95.3 in 90 in Height to Top of ROPS (folded) Not Published 73 in Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2266 lb 1444 lb Weight with ROPS and Loader 2972 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial Standard R4, optional R3 R1 Agricultural - Front 7-14 Not Published R1 Agricultural - Rear 11.2-24 Not Published R3 Turf - Front 27X8.50-15 18x8.5-10 R3 Turf - Rear 41X14-20 26x12-12 R4 Industrial - Front 25X8.50-14 or 27X8.50-15 18x8.5-10 R4 Industrial - Rear 15.00-19.5 or 43X16-20 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System Quick-change attachment carrier Quik-Park (MSL option on 120R) Loader Model D160 120R (NSL or MSL) or 120E (D120 and H120 on earlier units) Loader Lift Height 84 in 120R (NSL and MSL): 72 in; 120E: 71.2 in; D120 and H120: 71.2 in Loader Lift Capacity (Full Height) 1,186 lb 120R NSL: 752 lb (49 in bucket) or 704 lb (53 in bucket); 120R MSL: 548 lb (53 in bucket); D120: 825 lb; H120: 836 lb (all at pivot pin, max height) Loader Breakout Force 1,704 lb 120R NSL: 2008 lbf (49 in bucket) or 1816 lbf (53 in bucket); 120R MSL: 1591 lbf; D120: 1808 lbf; H120: 1819 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) 6-Year / 2,000 Hour Limited Powertrain Warranty; standard at no cost, covers residential and commercial use
