▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV88F-EPJT2 3TNV80F-NCJT Engine Type Diesel, naturally aspirated, direct injection Diesel No. of Cylinders 3 3 Displacement 100.2 in³ 77 in³ Rated Engine Speed 2400 rpm 3200 rpm Engine Power (Gross) 24.4 hp 23.2 hp PTO Power 19.4 hp 17.8 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water pump Liquid-cooled Air Cleaner Dry type with safety element Not Published Fuel System Direct injection Not Published Alternator 55 A, 12 V Not Published ▶ HydraulicsPump Type Implement/steering pump: tandem gear pump; hydrostatic pump: PV axial-piston pump Gear Implement Flow 5.3 gpm 3.5 gpm Steering Flow 4.0 gpm 3.5 gpm Total Hydraulic Flow 9.3 gpm 7 gpm Overall Hydraulic Pump Flow 9.3 gpm 7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 2 (optional) Not Published ▶ Fluid CapacityFuel Tank Capacity 7.5 gal 5.57 gal Coolant Capacity 5.2 qt Not Published Crankcase Capacity 4.5 qt Not Published Transmission / Hydraulic System Capacity 5.5 gal Not Published Front Axle Fluid Capacity 4 qt Not Published ▶ PTO & HitchPTO Type Not Published Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Standard, 2100 rpm Category, 3-Point Hitch Category I Limited Category I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 1,356 lb 758 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (HST) Hydrostatic - 2 range No. of Speeds Not Published Infinite (hydrostatic), 2 ranges forward and reverse Max Travel Speed (Forward) Not Published 9.1 mph Max Travel Speed (Reverse) Not Published 9.1 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Open operator station (OOS) Foldable ROPS, standard equipment Steering Power steering Power steering Brakes Wet disc Wet disc, left-hand pedal Seat Suspension & Adjustability Not Published Suspension seat, high back, adjustable settings; tilt steering Front Axle Type 4WD (MFWD) Four-wheel drive Front Axle Rating 1,760 lb Not Published Drawbar Capacity 880 lb (maximum vertical load) Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) 47.22 in (R3 tires); 47.32 in (R4 tires) Wheelbase 62.8 in 57.1 in Ground Clearance 12.7 in (R4 tires) Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 95.3 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 115.9 in (with 3-point hitch) Not Published ▶ WeightTractor Weight (Base) 2,222 lb 1,602 lb open station; 2,019 lb cab (shipping weight) Weight with ROPS and Loader 2,972 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial R3 Turf, R3 Hybrid, or R4 R1 Agricultural - Front 7-14 Not Published R1 Agricultural - Rear 11.2-24 Not Published R3 Turf - Front 27X8.50-15 18x8.50-10 R3 Turf - Rear 41X14-20 26x12-12 R4 Industrial - Front 25X8.50-14 or 27X8.50-15 18x8.5-10 R4 Industrial - Rear 15-19.5 or 43x16-20 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System Quick-change attachment carrier Tool-free attach and park Loader Model 300E 120R Loader Lift Height 84 in (at pivot pin) 120R: 72 in Loader Lift Capacity (Full Height) 1,186 lb (at pivot pin) 120R (NSL): 704 lb (at pivot, full height) Loader Breakout Force 1,704 lb (at pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours Powertrain 6 years or 2,000 hours, standard at no cost, covers residential and commercial use
