▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV88F-EPJT2 3TNV80F-NCJT Engine Type Diesel, naturally aspirated, direct injection Diesel No. of Cylinders 3 3 Displacement 95.7 in³ 77 in³ Rated Engine Speed 2400 rpm 3200 rpm Engine Power (Gross) 24.4 hp 23.9 hp PTO Power 17.4 hp 17.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water pump Water pump (liquid-cooled) Air Cleaner Dry type with safety element Dual element Fuel System Direct injection Indirect injection Alternator 55 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Implement/steering pump: Tandem gear; hydrostatic pump: PV axial piston Gear Implement Flow 5.3 gpm 3.5 gpm Steering Flow 4.0 gpm 3.5 gpm Total Hydraulic Flow 9.3 gpm 7 gpm Overall Hydraulic Pump Flow 9.3 gpm 7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 3.4 gpm implement circuit; 7.0 gpm combined pump output No. of Standard Remote Valves Not Published 0 No. of Optional Remote Valves Up to 2 (optional) 2 ▶ Fluid CapacityFuel Tank Capacity 7.5 gal 6.1 gal Coolant Capacity 1.3 gal 0.84 gal Crankcase Capacity 4.5 qt 0.84 gal Transmission / Hydraulic System Capacity 5.5 gal 3.5 gal Front Axle Fluid Capacity 1.0 gal 0.89 gal ▶ PTO & HitchPTO Type Not Published Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published 2000 rpm Category, 3-Point Hitch Category I Limited Category I Hitch Lift Capacity 1,356 lb @ 24 in behind link arms 1433 lb Hitch Lift Capacity (at 24”) 1356 lb 915 lb Lift Control Type Not Published Position Control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (HST) Hydrostatic No. of Speeds Not Published Two range (Hi and Lo) Max Travel Speed (Forward) Not Published 12.3 mph Max Travel Speed (Reverse) Not Published 11.4 mph Clutch Not Published wet disc Differential Lock & Limited Slip Options Not Published Differential lock: Yes; Limited slip differential: No ▶ Chassis, Steering & ControlsFrame Type Open operator station (OOS) Open center; spur gear final drive; wet disc brakes Steering Hydrostatic Power Brakes Wet disc Wet Disc Seat Suspension & Adjustability Not Published Fore/aft adjustable; seat flips forward for weather protection; no mechanical suspension listed Front Axle Type 4WD (MFWD) Four-wheel drive Front Axle Rating 1760 lb 1940 lb Drawbar Capacity 880 lb 562 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 115.9 in 109.2 in Overall Width 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) 37 in (min); 51 in (max) Wheelbase 62.8 in 63 in Ground Clearance 12.7 in (R4 tires) 12.5 in Min. Turn Radius without Brakes 9.4 ft (2.9 m) 2.51 m 8.2 ft Height to Top of ROPS 95.3 in 89 in Height to Top of ROPS (folded) Not Published 66.8 in Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2266 lb 1660 lb Weight with ROPS and Loader 2972 lb ~2,005 lb (open station shipping weight 1,872 lb / 1,871.7 lb base; with H130 loader approx. 2,005 lb estimated) Weight with Cab and Loader Not Published ~2,392 lb base cab shipping weight (loader weight additive) ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial Front: 23x8.5-12 (R4 industrial / R3 turf); Rear: 31x12-16.5 (R4 industrial / R3 turf) R1 Agricultural - Front 7-14 Not Published R1 Agricultural - Rear 11.2-24 Not Published R3 Turf - Front 27X8.50-15 23x8.50-12 or R3 Radial: 220/55-R12 R3 Turf - Rear 41X14-20 12-16.5 or R3 Radial: 280/70 R16 R4 Industrial - Front 25X8.50-14 or 27X8.50-15 23x8.50-12 R4 Industrial - Rear 15.00-19.5 or 43X16-20 31x12.00-16.5 ▶ Loader & AttachmentsQuick Attach Loader System Quick-change attachment carrier H130 Loader (Quik-Park); 120R Loader (NSL standard, MSL optional, Quik-Park) Loader Model D160 H130 or 120R Loader Lift Height 84 in H130: 78.9 in; 120R: 72 in (at pivot pin) Loader Lift Capacity (Full Height) 1,186 lb H130: 1,023 lb; 120R (NSL): 803 lb (at pivot pin, full height) Loader Breakout Force 1,704 lb H130: 2,508 lbf (at pivot pin); 120R: Not Published ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) 2-year bumper-to-bumper (comprehensive) + 6-year/2,000-hour powertrain warranty
