▶ EngineEngine Manufacturer Yanmar Mitsubishi Engine Model 3TNV88F-EPJT2 S3L2 Engine Type Diesel, naturally aspirated, direct injection Four stroke, indirect injection water-cooled diesel No. of Cylinders 3 3 Displacement 95.7 in³ 80.4 in³ Rated Engine Speed 2400 rpm 2500 rpm Engine Power (Gross) 24.4 hp 24.4 hp PTO Power 17.4 hp 19.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water pump Water-cooled Air Cleaner Dry type with safety element Not Published Fuel System Direct injection Indirect Injection Alternator 55 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Implement/steering pump: Tandem gear; hydrostatic pump: PV axial piston Not Published Implement Flow 5.3 gpm 4.6 gpm Steering Flow 4.0 gpm 2.7 gpm Total Hydraulic Flow 9.3 gpm Not Published Overall Hydraulic Pump Flow 9.3 gpm Not Published Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 2 (optional) 1 ▶ Fluid CapacityFuel Tank Capacity 7.5 gal 6.1 gal Coolant Capacity 1.3 gal Not Published Crankcase Capacity 4.5 qt Not Published Transmission / Hydraulic System Capacity 5.5 gal Not Published Front Axle Fluid Capacity 1.0 gal Not Published ▶ PTO & HitchPTO Type Not Published Live PTO Rear 540 rpm 540 @ 2376 rpm Mid-PTO Availability Not Published Available; 2000 @ 2556 rpm Category, 3-Point Hitch Category I Category I, with check chains Hitch Lift Capacity 1,356 lb @ 24 in behind link arms 1400 lb Hitch Lift Capacity (at 24”) 1356 lb Not Published Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (HST) HST - 2 ranges No. of Speeds Not Published Infinite Max Travel Speed (Forward) Not Published 9.6 mph Max Travel Speed (Reverse) Not Published 4.9 mph Clutch Not Published Single plate, dry Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Open operator station (OOS) Not Published Steering Hydrostatic Hydrostatic power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type 4WD (MFWD) Not Published Front Axle Rating 1760 lb Not Published Drawbar Capacity 880 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 115.9 in 104.1 in Overall Width 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) 50.7 in Wheelbase 62.8 in Not Published Ground Clearance 12.7 in (R4 tires) Not Published Min. Turn Radius without Brakes 9.4 ft (2.9 m) 7.2 ft Height to Top of ROPS 95.3 in 81.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2266 lb 1693 lb Weight with ROPS and Loader 2972 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial Not Published R1 Agricultural - Front 7-14 6x12 R1 Agricultural - Rear 11.2-24 9.5x16 R3 Turf - Front 27X8.50-15 20x8-10 R3 Turf - Rear 41X14-20 29x12.5-15 R4 Industrial - Front 25X8.50-14 or 27X8.50-15 20x8-10 R4 Industrial - Rear 15.00-19.5 or 43X16-20 27x12.5-15 ▶ Loader & AttachmentsQuick Attach Loader System Quick-change attachment carrier Not Published Loader Model D160 Max 24L Loader Lift Height 84 in Max 24L: 75 in Loader Lift Capacity (Full Height) 1,186 lb Max 24L: 900 lb (at pivot pin) Loader Breakout Force 1,704 lb Max 24L: 2000 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) Two Year All Aggregate (bumper to bumper) plus Five-Year Limited Powertrain; extends to a total 7-year / 3000 Hrs Limited Powertrain on eligible non-commercial, residential purchases
