▶ EngineEngine Manufacturer Yanmar Kubota Engine Model 3TNV88C-NJT2 V1505-CR-TE5-D36R1 Engine Type Diesel, naturally aspirated E-CDIS, liquid cooled, 4-cylinder, diesel No. of Cylinders 3 4 Displacement 100.2 in³ 91.5 in³ Rated Engine Speed 2500 rpm 2500 rpm Engine Power (Gross) 30.7 hp 30.8 hp PTO Power 25 hp 27 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water pump Pressurized radiator Air Cleaner Dry type with safety element 6.0 in Dual paper element Fuel System High pressure common rail direct injection Common Rail System (CRS) Alternator 55 A, 12 V 60 A, 12 V ▶ HydraulicsPump Type Implement/steering pump: tandem gear pump; hydrostatic pump: PV axial-piston pump Dual pump Implement Flow 5.3 gpm 5.0 gpm Steering Flow 4.0 gpm 3.7 gpm Total Hydraulic Flow 9.3 gpm 8.7 gpm Overall Hydraulic Pump Flow 9.3 gpm 8.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None No. of Optional Remote Valves Not Published Optional, up to 2 ▶ Fluid CapacityFuel Tank Capacity 7.5 gal 7.1 gal Coolant Capacity 5.2 qt 4.5 qt Crankcase Capacity 4.7 qt 5.0 qt Transmission / Hydraulic System Capacity 5.5 gal 4.0 gal Front Axle Fluid Capacity 4 qt 5.0 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published 2500 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity Not Published 2,139 lb Hitch Lift Capacity (at 24”) 1,356 lb 1,676 lb Lift Control Type Position control Position control valve ▶ Transmission & DrivetrainTransmission Type Hydrostatic (2-range) Hydrostatic transmission No. of Speeds Infinite (2-range HST) 3 ranges Max Travel Speed (Forward) Not Published 13.6 mph Max Travel Speed (Reverse) Not Published 10.3 mph Clutch Not Published Not Applicable Differential Lock & Limited Slip Options Not Published Differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydraulic power steering Brakes Wet disc Multi-plate wet disc Seat Suspension & Adjustability Not Published Deluxe high-back suspension seat Front Axle Type 4WD (MFWD) Not Published Front Axle Rating 1,760 lb Not Published Drawbar Capacity 880 lb (maximum vertical load) 1,100 lb ▶ Dimensions & ManeuverabilityOverall Width 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) 53.7 in Wheelbase 62.8 in 65.6 in Ground Clearance 12.7 in (R4 tires) 14.6 in Min. Turn Radius without Brakes Not Published 6.9 ft (with brake applied) Height to Top of ROPS 95.3 in 88.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Applicable Overall Length 115.9 in (with 3-point hitch) 101.8 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 2,222 lb 2,072 lb Weight with ROPS and Loader 2,972 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial, R14 R1 Agricultural - Front 7-14 7-12 R1 Agricultural - Rear 11.2-24 12.4-16 R3 Turf - Front 27X8.50-15 24x8.50-14 R3 Turf - Rear 41X14-20 13.6-16 R4 Industrial - Front 25X8.50-14 or 27X8.50-15 23X8.50-14 / 25X8.50-14 R4 Industrial - Rear 15-19.5 or 43x16-20 12.4-16 / 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Quick-change attachment carrier LA535: 2-lever quick coupler, standard; Swift-Tach, optional Loader Model 300E LA535 Loader Lift Height 84.0 in (at pivot pin) 84 in Loader Lift Capacity (Full Height) 1,186 lb (at pivot pin) 1,067 lb Loader Breakout Force 1,704 lb (at pivot pin) 2,245 lb ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
