▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV88C-MJT 3TNV88C-NJT2 Engine Type Diesel, turbocharged Diesel No. of Cylinders 3 3 Displacement 97.6 in³ 100.2 in³ Rated Engine Speed 2600 rpm 2500 rpm Engine Power (Gross) 31.8 hp 31.2 hp PTO Power 24.3 hp 24.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water pump Liquid-cooled Air Cleaner Dry type with safety element Dual element Fuel System High pressure common rail direct injection (HPCR) Direct injection Alternator 75 A, 12 V 85 A, 12 V ▶ HydraulicsPump Type Implement/steering pump: Dual gear; hydrostatic pump: PV axial piston Tandem gear Implement Flow 8.6 gpm 5.3 gpm Steering Flow 5.9 gpm 4 gpm Total Hydraulic Flow 14.4 gpm 9.3 gpm Overall Hydraulic Pump Flow 14.4 gpm 9.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 6 rear remotes Up to 3 ▶ Fluid CapacityFuel Tank Capacity Open station: 13.5 gal; Cab: 11.8 gal 8.5 gal Coolant Capacity 1.4 gal 4.2 qt Crankcase Capacity 1.1 gal 4.7 qt Transmission / Hydraulic System Capacity 6.8 gal 4.6 gal Front Axle Fluid Capacity 1.3 gal 4.1 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not applicable 2100 rpm Category, 3-Point Hitch Limited Category 1 Category 1 Hitch Lift Capacity 2530 lb at hitch ball 1433 lb Hitch Lift Capacity (at 24”) 2,194 lb at 24 in behind link arms 1356 lb Lift Control Type Position control Position Control ▶ Transmission & DrivetrainTransmission Type 12F/12R Hydrostatic No. of Speeds 12F/12R Infinite (2-range) Max Travel Speed (Forward) 18.50 mph Not Published Max Travel Speed (Reverse) 18.50 mph Not Published Clutch Wet disk Not Published Differential Lock & Limited Slip Options Differential lock: Yes Differential lock ▶ Chassis, Steering & ControlsFrame Type Foldable ROPS; cab or open station configurations available Open station with foldable ROPS Steering Hydrostatic power steering Power Brakes Multi-plate wet disk Wet Disc Seat Suspension & Adjustability Standard seat: height/level/fore-aft adjustments; Deluxe seat: weight (air pressure) & fore-aft adjustments Marine-grade seat Front Axle Type Mechanical front wheel drive (MFWD) Not Published Front Axle Rating 3196 lb 1940 lb Drawbar Capacity 899 lbf 562 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 120.2 in 115.2 in Overall Width 69.1 in 55.6 in Wheelbase 68.0 in 65.2 in Ground Clearance 12.2 in 13 in Min. Turn Radius without Brakes 8.8 ft (2.68 m, MFWD off) 98.4 in Height to Top of ROPS 93.3 in 89.7 in Height to Top of ROPS (folded) 72.0 in 67.5 in Height to Top of Cab Model 85.0 in Not Published ▶ WeightTractor Weight (Base) 2900 lb 1973 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial R1 Ag, R3 Turf, R4 Industrial, R3 Turf Radial R1 Agricultural - Front 7-14 7.00-12 R1 Agricultural - Rear 11.2-24 12.4-16 R3 Turf - Front 27X8.50-15 23X8.50-14 R3 Turf - Rear 41X14-20 14-17.5 R4 Industrial - Front 25X8.5-14 or 27X8.5-15 23x8.50-14 R4 Industrial - Rear 15-19.5 or 43X16-20 14-17.5 ▶ Loader & AttachmentsQuick Attach Loader System Quik-Park mounting system H130 Loader Loader Model H160 H130 or 220R Loader Lift Height 90 in H130: 78.5 in; 220R: 85 in (at pivot pin) Loader Lift Capacity (Full Height) 1,360 lb at pivot; 999 lb @ 19.7 in ahead of pivot H130: 1,027 lb; 220R: 1,120 lb (at pivot pin, full height) Loader Breakout Force 2,855 lb at pivot; 2,032 lb @ 19.7 in H130: 2,363 lbf; 220R: 1,949 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
