▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV88C-MJT 3TNV88C-NJT Engine Type Diesel, turbocharged Diesel, turbocharged No. of Cylinders 3 3 Displacement 97.6 in³ 95.8 in³ Rated Engine Speed 2600 rpm 2500 rpm Engine Power (Gross) 31.8 hp 36.7 hp PTO Power 24.3 hp 30.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water pump Liquid-cooled Air Cleaner Dry type with safety element Dual element Fuel System High pressure common rail direct injection (HPCR) Direct injection Alternator 75 A, 12 V 85 A, 12 V ▶ HydraulicsPump Type Implement/steering pump: Dual gear; hydrostatic pump: PV axial piston Dual gear Implement Flow 8.6 gpm 5.3 gpm Steering Flow 5.9 gpm 4 gpm Total Hydraulic Flow 14.4 gpm 9.3 gpm Overall Hydraulic Pump Flow 14.4 gpm 9.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 6 rear remotes Up to 3 ▶ Fluid CapacityFuel Tank Capacity Open station: 13.5 gal; Cab: 11.8 gal 8.5 gal Coolant Capacity 1.4 gal 1.37 gal Crankcase Capacity 1.1 gal 4.7 qt Transmission / Hydraulic System Capacity 6.8 gal 6.2 gal Front Axle Fluid Capacity 1.3 gal 1.0 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not applicable 2000 rpm Category, 3-Point Hitch Limited Category 1 Category 1 Hitch Lift Capacity 2530 lb at hitch ball 1,356 lb Hitch Lift Capacity (at 24”) 2,194 lb at 24 in behind link arms 1356 lb Lift Control Type Position control Position Control ▶ Transmission & DrivetrainTransmission Type 12F/12R Hydrostatic No. of Speeds 12F/12R Infinite (2-range HST) Max Travel Speed (Forward) 18.50 mph 15.3 mph Max Travel Speed (Reverse) 18.50 mph Not Published Clutch Wet disk Not Published Differential Lock & Limited Slip Options Differential lock: Yes Differential lock: Yes; Limited slip: Not Published ▶ Chassis, Steering & ControlsFrame Type Foldable ROPS; cab or open station configurations available Not Published Steering Hydrostatic power steering Power Brakes Multi-plate wet disk Wet Disc Seat Suspension & Adjustability Standard seat: height/level/fore-aft adjustments; Deluxe seat: weight (air pressure) & fore-aft adjustments Not Published Front Axle Type Mechanical front wheel drive (MFWD) 4WD (MFWD) Front Axle Rating 3196 lb 1940 lb Drawbar Capacity 899 lbf Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 120.2 in 117.7 in Overall Width 69.1 in 53.9 in Wheelbase 68.0 in 67.9 in Ground Clearance 12.2 in Not Published Min. Turn Radius without Brakes 8.8 ft (2.68 m, MFWD off) Not Published Height to Top of ROPS 93.3 in 92.3 in Height to Top of ROPS (folded) 72.0 in Not Published Height to Top of Cab Model 85.0 in Not Published ▶ WeightTractor Weight (Base) 2900 lb 2436 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial R1 Ag, R3 Turf, R4 Industrial, R3 Turf Radial R1 Agricultural - Front 7-14 7.00-12 R1 Agricultural - Rear 11.2-24 12.4-16 R3 Turf - Front 27X8.50-15 23x8.50-14 R3 Turf - Rear 41X14-20 14-17.5 R4 Industrial - Front 25X8.5-14 or 27X8.5-15 23x8.50-14 R4 Industrial - Rear 15-19.5 or 43X16-20 14-17.5 ▶ Loader & AttachmentsQuick Attach Loader System Quik-Park mounting system 220R Quik-Park Loader System Loader Model H160 220R Loader Lift Height 90 in 85 in (at pivot pin) Loader Lift Capacity (Full Height) 1,360 lb at pivot; 999 lb @ 19.7 in ahead of pivot 1,120 lb (at pivot pin, full height) Loader Breakout Force 2,855 lb at pivot; 2,032 lb @ 19.7 in 1,949 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
