▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV88C-MJT 3TNV88C-NJT2 Engine Type Diesel Diesel, naturally aspirated No. of Cylinders 3 3 Displacement 100.2 in³ 100.2 in³ Rated Engine Speed 2600 rpm 2500 rpm Engine Power (Gross) 31.8 hp 30.7 hp PTO Power 24.3 hp 25 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid Water pump Air Cleaner Dry type with safety element Dry type with safety element Fuel System Not Published High pressure common rail direct injection Alternator 75 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Implement/steering pump: dual gear pump Implement/steering pump: tandem gear pump; hydrostatic pump: PV axial-piston pump Implement Flow 9.1 gpm 5.3 gpm Steering Flow 6.2 gpm 4.0 gpm Total Hydraulic Flow 15.3 gpm 9.3 gpm Overall Hydraulic Pump Flow 15.3 gpm 9.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity Open station: 13.5 gal; Cab: 11.8 gal 7.5 gal Coolant Capacity Open station (OOS): 1.4 gal; Cab: 1.9 gal 5.2 qt Crankcase Capacity 1.1 gal 4.7 qt Transmission / Hydraulic System Capacity 6.8 gal 5.5 gal Front Axle Fluid Capacity 1.3 gal 4 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not applicable Not Published Category, 3-Point Hitch Limited Category I Category I Hitch Lift Capacity 2,530 lb at hitch ball Not Published Hitch Lift Capacity (at 24”) 2,200 lb 1,356 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type 12F/12R Hydrostatic (2-range) No. of Speeds 12F/12R Infinite (2-range HST) Max Travel Speed (Forward) 18.50 mph Not Published Max Travel Speed (Reverse) 18.50 mph Not Published Clutch Wet disc Not Published Differential Lock & Limited Slip Options Differential lock: Yes Not Published ▶ Chassis, Steering & ControlsFrame Type Foldable ROPS; cab or open station configurations available Not Published Steering Hydrostatic power steering Power steering Brakes Multi-plate wet disk Wet disc Seat Suspension & Adjustability Standard seat: height, level and fore-aft adjustment; upgraded seat: weight (air pressure) and fore-aft adjustment Not Published Front Axle Type Mechanical front wheel drive (MFWD) 4WD (MFWD) Front Axle Rating 3,196 lb 1,760 lb Drawbar Capacity Not Published 880 lb (maximum vertical load) ▶ Dimensions & ManeuverabilityOverall Width 69.1 in 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) Wheelbase 68.0 in 62.8 in Ground Clearance 12.2 in 12.7 in (R4 tires) Min. Turn Radius without Brakes 8.8 ft (2.68 m, MFWD off) Not Published Height to Top of ROPS 93.3 in 95.3 in Height to Top of ROPS (folded) 72.0 in Not Published Height to Top of Cab Model 85.0 in Not Published Overall Length 120.2 in (with 3-point hitch) 115.9 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,900 lb 2,222 lb Weight with ROPS and Loader Not Published 2,972 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 7-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 27X8.50-15 27X8.50-15 R3 Turf - Rear 41X14-20 41X14-20 R4 Industrial - Front 25X8.5-14 or 27X8.5-15 25X8.50-14 or 27X8.50-15 R4 Industrial - Rear 15-19.5 or 43X16-20 15-19.5 or 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System Tool-free attach-and-park mounting Quick-change attachment carrier Loader Model 300R; 320R 300E Loader Lift Height 300R: 90 in; 320R: 102 in 84.0 in (at pivot pin) Loader Lift Capacity (Full Height) 300R: 1,360 lb; 320R: 1,598 lb (at pivot pin) 1,186 lb (at pivot pin) Loader Breakout Force 300R: 2,855 lbf; 320R: 3,327 lbf (at pivot pin) 1,704 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours
