▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV88C-MJT 3TNV88C-MJT Engine Type Diesel, turbocharged Diesel, turbocharged No. of Cylinders 3 3 Displacement 97.6 in³ 97.6 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 31.8 hp 31.8 hp PTO Power 24.3 hp 24.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water pump Water pump Air Cleaner Dry type with safety element Dry type with safety element Fuel System High pressure common rail direct injection (HPCR) High pressure common rail direct injection (HPCR) Alternator 75 A, 12 V 75 A, 12 V ▶ HydraulicsPump Type Implement/steering pump: Dual gear; hydrostatic pump: PV axial piston Implement/steering pump: Dual gear; hydrostatic pump: PV axial piston Implement Flow 8.6 gpm 8.6 gpm Steering Flow 5.9 gpm 5.9 gpm Total Hydraulic Flow 14.4 gpm 14.4 gpm Overall Hydraulic Pump Flow 14.4 gpm 14.4 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 6 rear remotes Up to 6 rear remotes ▶ Fluid CapacityFuel Tank Capacity Open station: 13.5 gal; Cab: 11.8 gal Open station: 13.5 gal; Cab: 11.8 gal Coolant Capacity 1.4 gal 1.4 gal Crankcase Capacity 1.1 gal 1.1 gal Transmission / Hydraulic System Capacity 6.8 gal 6.8 gal Front Axle Fluid Capacity 1.3 gal 1.3 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not applicable Optional (2100 rpm) Category, 3-Point Hitch Limited Category 1 Limited Category 1 Hitch Lift Capacity 2530 lb at hitch ball 2530 lb at hitch ball Hitch Lift Capacity (at 24”) 2,194 lb at 24 in behind link arms 2,194 lb at 24 in behind link arms Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type 12F/12R three-range, infinitely variable No. of Speeds 12F/12R infinite in 3 ranges Max Travel Speed (Forward) 18.50 mph 18.50 mph Max Travel Speed (Reverse) 18.50 mph 18.50 mph Clutch Wet disk Not Applicable Differential Lock & Limited Slip Options Differential lock: Yes Differential lock: Yes ▶ Chassis, Steering & ControlsFrame Type Foldable ROPS; cab or open station configurations available Foldable ROPS; cab or open station configurations available Steering Hydrostatic power steering Hydrostatic power steering Brakes Multi-plate wet disk Multi-plate wet disk Seat Suspension & Adjustability Standard seat: height/level/fore-aft adjustments; Deluxe seat: weight (air pressure) & fore-aft adjustments Standard seat: height/level/fore-aft adjustments; Deluxe seat: weight (air pressure) & fore-aft adjustments Front Axle Type Mechanical front wheel drive (MFWD) Mechanical front wheel drive (MFWD) Front Axle Rating 3196 lb 3196 lb Drawbar Capacity 899 lbf 899 lbf ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 120.2 in 120.2 in Overall Width 69.1 in 69.1 in Wheelbase 68.0 in 68.0 in Ground Clearance 12.2 in 12.2 in Min. Turn Radius without Brakes 8.8 ft (2.68 m, MFWD off) 8.8 ft (2.68 m, MFWD off) Height to Top of ROPS 93.3 in 93.3 in Height to Top of ROPS (folded) 72.0 in 72.0 in Height to Top of Cab Model 85.0 in 85.0 in ▶ WeightTractor Weight (Base) 2900 lb 2900 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 7-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 27X8.50-15 27X8.50-15 R3 Turf - Rear 41X14-20 41X14-20 R4 Industrial - Front 25X8.5-14 or 27X8.5-15 25X8.5-14 or 27X8.5-15 R4 Industrial - Rear 15-19.5 or 43X16-20 15-19.5 or 43X16-20 ▶ Loader & AttachmentsQuick Attach Loader System Quik-Park mounting system Quik-Park mounting system Loader Model H160 H160 Loader Lift Height 90 in 90 in Loader Lift Capacity (Full Height) 1,360 lb at pivot; 999 lb @ 19.7 in ahead of pivot 1,360 lb at pivot; 999 lb @ 19.7 in ahead of pivot Loader Breakout Force 2,855 lb at pivot; 2,032 lb @ 19.7 in 2,855 lb at pivot; 2,032 lb @ 19.7 in ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
