▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV88C-MJT 3TNV88-BMJT Engine Type Diesel 3-cylinder diesel, direct injection No. of Cylinders 3 3 Displacement 100.2 in³ 100.1 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 31.8 hp 32.4 hp PTO Power 24.3 hp 25.5 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid Liquid-cooled Air Cleaner Dry type with safety element Dry type with safety element Fuel System Not Published Direct injection, self-bleeding in-line fuel pump, electric shutoff Alternator 75 A, 12 V 40 A ▶ HydraulicsPump Type Implement/steering pump: dual gear pump Dual tandem gear pump Implement Flow 9.1 gpm 8.6 gpm Steering Flow 6.2 gpm 5.3 gpm Total Hydraulic Flow 15.3 gpm 13.9 gpm Overall Hydraulic Pump Flow 15.3 gpm 13.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity Open station: 13.5 gal; Cab: 11.8 gal 13.5 gal (open station); 11.8 gal (cab) Coolant Capacity Open station (OOS): 1.4 gal; Cab: 1.9 gal 1.4 gal (open station); 1.8 gal (cab) Crankcase Capacity 1.1 gal 5.1 qt Transmission / Hydraulic System Capacity 6.8 gal 6.8 gal (eHydro); 6.3 gal (PowrReverser) Front Axle Fluid Capacity 1.3 gal 1.2 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not applicable Optional, 2100 rpm Category, 3-Point Hitch Limited Category I Category 1 Hitch Lift Capacity 2,530 lb at hitch ball 2,530 lb Hitch Lift Capacity (at 24”) 2,200 lb 2,200 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type 12F/12R eHydro 3-range hydrostatic (4WD); PowrReverser 12F/12R power shuttle (4WD) No. of Speeds 12F/12R Infinite forward and reverse, 3 ranges (eHydro); 12 forward, 12 reverse (PowrReverser) Max Travel Speed (Forward) 18.50 mph 19 mph (eHydro); 16.4 mph (PowrReverser) Max Travel Speed (Reverse) 18.50 mph 19 mph (eHydro); 16.4 mph (PowrReverser) Clutch Wet disc Multiple stage wet disc, 4.4 in (PowrReverser) Differential Lock & Limited Slip Options Differential lock: Yes Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Foldable ROPS; cab or open station configurations available Folding ROPS; MFWD standard; cab optional Steering Hydrostatic power steering Hydrostatic power steering Brakes Multi-plate wet disk Wet disk Seat Suspension & Adjustability Standard seat: height, level and fore-aft adjustment; upgraded seat: weight (air pressure) and fore-aft adjustment Not Published Front Axle Type Mechanical front wheel drive (MFWD) Mechanical front wheel drive (MFWD), standard, all ranges Front Axle Rating 3,196 lb 1,587 to 3,197 lb (operating capacity) Drawbar Capacity Not Published Drawbar tongue capacity: 882 lb; maximum static vertical load: 562 lb ▶ Dimensions & ManeuverabilityOverall Width 69.1 in 52.4 in (minimum, R1 tires); 68.4 in (maximum, R1 tires) Wheelbase 68.0 in 68 in Ground Clearance 12.2 in Not Published Min. Turn Radius without Brakes 8.8 ft (2.68 m, MFWD off) Not Published Height to Top of ROPS 93.3 in 93.3 in Height to Top of ROPS (folded) 72.0 in Not Published Height to Top of Cab Model 85.0 in 89.4 in Overall Length 120.2 in (with 3-point hitch) 120.2 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,900 lb 2,900 lb (open station); 3,570 lb (cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial R1 bar tread, R3 turf, R4 industrial and golf tires available on all models R1 Agricultural - Front 7-14 7.00-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 27X8.50-15 27x8.50-15 R3 Turf - Rear 41X14-20 41x14.00-20 R4 Industrial - Front 25X8.5-14 or 27X8.5-15 25x8.50-14 or 27x8.50-15 R4 Industrial - Rear 15-19.5 or 43X16-20 43x16.00-20 or 15.00-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Tool-free attach-and-park mounting Quik-Park loader attaches and detaches in less than three minutes with no tools Loader Model 300R; 320R H160; H165 Loader Lift Height 300R: 90 in; 320R: 102 in H160: 90 in; H165: 102 in Loader Lift Capacity (Full Height) 300R: 1,360 lb; 320R: 1,598 lb (at pivot pin) H160: 1,360 lb; H165: 1,598 lb (to maximum height at pivot point) Loader Breakout Force 300R: 2,855 lbf; 320R: 3,327 lbf (at pivot pin) H160: 2,855 lbf; H165: 3,327 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours Not Published
