▶ EngineEngine Manufacturer Yanmar YANMAR Engine Model 3TNV88C-MJT 3TNV88C-MLST Engine Type Diesel 3-cylinder, liquid-cooled, diesel, naturally aspirated, CRDI No. of Cylinders 3 3 Displacement 100.2 in³ 100.2 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 31.8 hp 31.7 hp PTO Power 24.3 hp 28.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid Liquid-cooled Air Cleaner Dry type with safety element Dry Fuel System Not Published CRDI (common rail direct injection) Alternator 75 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Implement/steering pump: dual gear pump Gear pump Implement Flow 9.1 gpm 7.4 gpm Steering Flow 6.2 gpm 5.0 gpm Total Hydraulic Flow 15.3 gpm 12.4 gpm Overall Hydraulic Pump Flow 15.3 gpm 12.4 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None No. of Optional Remote Valves Not Published 1 pair (optional) ▶ Fluid CapacityFuel Tank Capacity Open station: 13.5 gal; Cab: 11.8 gal 10.6 gal Coolant Capacity Open station (OOS): 1.4 gal; Cab: 1.9 gal Not Published Crankcase Capacity 1.1 gal Not Published Transmission / Hydraulic System Capacity 6.8 gal Not Published Front Axle Fluid Capacity 1.3 gal Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm Standard (540 rpm) Mid-PTO Availability Not applicable Available (option) Category, 3-Point Hitch Limited Category I Category I Hitch Lift Capacity 2,530 lb at hitch ball 1,808 lb Hitch Lift Capacity (at 24”) 2,200 lb 1,433 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type 12F/12R Synchro Shuttle No. of Speeds 12F/12R F12 x R12 Max Travel Speed (Forward) 18.50 mph Not Published Max Travel Speed (Reverse) 18.50 mph Not Published Clutch Wet disc Dry Single Differential Lock & Limited Slip Options Differential lock: Yes Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Foldable ROPS; cab or open station configurations available Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Multi-plate wet disk Wet, multi-disc Seat Suspension & Adjustability Standard seat: height, level and fore-aft adjustment; upgraded seat: weight (air pressure) and fore-aft adjustment Not Published Front Axle Type Mechanical front wheel drive (MFWD) Not Published Front Axle Rating 3,196 lb Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 69.1 in 66 in Wheelbase 68.0 in 69 in Ground Clearance 12.2 in Not Published Min. Turn Radius without Brakes 8.8 ft (2.68 m, MFWD off) 11.5 ft (3.5 m) Height to Top of ROPS 93.3 in 95 in Height to Top of ROPS (folded) 72.0 in Not Published Height to Top of Cab Model 85.0 in Not Published Overall Length 120.2 in (with 3-point hitch) 125 in (frame to link) ▶ WeightTractor Weight (Base) 2,900 lb 3,166 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial Ag, Industrial, VT and Turf; VT same size as Industrial R1 Agricultural - Front 7-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 27X8.50-15 25x8.50-14 R3 Turf - Rear 41X14-20 41x14.00-20 R4 Industrial - Front 25X8.5-14 or 27X8.5-15 27x8.50-15 R4 Industrial - Rear 15-19.5 or 43X16-20 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System Tool-free attach-and-park mounting LL3003: ISO 24410 Quick Attaching Coupler Loader Model 300R; 320R LL3003 Loader Lift Height 300R: 90 in; 320R: 102 in LL3003: 94.3 in Loader Lift Capacity (Full Height) 300R: 1,360 lb; 320R: 1,598 lb (at pivot pin) LL3003: 2,063 lb (at pivot pin, maximum height) Loader Breakout Force 300R: 2,855 lbf; 320R: 3,327 lbf (at pivot pin) LL3003: 3,723 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours Two-year bumper to bumper; six-year limited powertrain
