▶ EnginePTO Power 30.4 hp 24.2 hp Alternator 55 A, 12 V 85 A, 12 V Air Cleaner Dual element Dual element Engine Type Liquid-cooled diesel, naturally aspirated, Diesel Fuel System High pressure common rail direct injection Direct injection Displacement 100.1 in³ 100.2 in³ No. of Cylinders 3 3 Rated Engine Speed 2800 rpm 2500 rpm Cooling System Type Liquid Liquid-cooled Engine Manufacturer Yanmar Yanmar Engine Power (Gross) 34.2 hp 30.7 hp @ 500 rpm Engine Emissions Constraints Tier 4 Tier 4 ▶ WeightWeight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Applicable Not Applicable ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) ▶ HydraulicsPump Type Single gear Tandem gear Steering Flow 4.4 gpm 4.0 gpm Implement Flow 5.9 gpm 5.3 gpm Total Hydraulic Flow 10.3 gpm 9.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 10.3 gpm 9.3 gpm No. of Optional Remote Valves Up to two (optional) Up to 3 No. of Standard Remote Valves Not Published Not Published ▶ PTO & HitchPTO Rear 540 rpm at 2400 rpm engine 543 rpm PTO Type Mechanical control; transmission clutch; wet disk brake (mid/rear PTO) Independent Lift Control Type Position control Position control Hitch Lift Capacity Not Published Not Published Mid-PTO Availability Not Published Yes (1998 rpm) Category, 3-Point Hitch Category 1 Category 1 Hitch Lift Capacity (at 24”) 2081.2 lb Not Published ▶ Tire OptionsR3 Turf - Rear 41X14-20 14-17.5 R3 Turf - Front 27X8.5-15 23X8.50-14 Tire Size & Options R1 Bar, R3 Turf, R4 Industrial R1 Ag, R3 Turf, R4 Industrial, R3 Turf Radial R4 Industrial - Rear 15-19.5 14-17.5 R4 Industrial - Front 25X8.5-14 23x8.50-14 R1 Agricultural - Rear 11.2-24 12.4-16 R1 Agricultural - Front 7-14 7.00-12 ▶ Fluid CapacityCoolant Capacity 1.2 gal 5.2 qt Crankcase Capacity 1.1 gal 4.5 qt Fuel Tank Capacity 10.0 gal 8.5 gal Front Axle Fluid Capacity 1.0 gal 4.0 qt Transmission / Hydraulic System Capacity 9.2 gal 6.2 gal ▶ Loader & AttachmentsLoader Lift Height 84.0 in 85 in Loader Breakout Force 1,704 lb 1,949 lbf Quick Attach Loader System Quick-change attachment carrier Quik-Park Loader Lift Capacity (Full Height) 1,186 lb 1,120 lb ▶ Transmission & DrivetrainClutch Single dry traction clutch Not Applicable No. of Speeds 8F/8R Infinite (2-range) Transmission Type 8F/8R synchromesh shuttle shift gear transmission Hydrostatic - two range Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Differential Lock & Limited Slip Options Differential lock: Yes; limited slip: Not Published Differential lock ▶ Chassis, Steering & ControlsBrakes Wet disk Wet disc Steering Power steering Power steering Frame Type Not Published Open station with foldable ROPS Front Axle Type MFWD (4WD) Not Published Drawbar Capacity Not Published Not Published Front Axle Rating 1940 lb 1,940 lb Seat Suspension & Adjustability Not Published Marine-grade seat ▶ Dimensions & ManeuverabilityWheelbase 62 in 67.8 in Overall Width 57.3 in [at 44.5 in rear tread] 55.1 in Ground Clearance 13.0 in minimum 9.8 in Height to Top of ROPS Not Published 92.3 in Height to Top of Cab Model Not Applicable Not Applicable Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes Not Published 98.4 in Overall Length with 3-Point Hitch Not Published 117.5 in
