▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV88C-KJPT 3TNV88C-NJT Engine Type 4-cycle, inline, water-cooled diesel, naturally aspirated Diesel No. of Cylinders 3 3 Displacement 100.2 in³ 95.8 in³ Rated Engine Speed 2800 rpm 2500 rpm Engine Power (Gross) 34.2 hp 36.7 hp PTO Power 30.4 hp 30.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid Liquid-cooled Air Cleaner Dry Dual element Fuel System Direct injection Direct injection Alternator 55 A, 12 V 85 A ▶ HydraulicsPump Type 2 single-section external gear pumps, 1 on each side of the engine timing-gear cover Tandem gear Implement Flow 5.9 gpm 5.3 gpm Steering Flow 4.4 gpm 4 gpm Total Hydraulic Flow 10.3 gpm 9.3 gpm Overall Hydraulic Pump Flow 10.3 gpm 9.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None Not Published No. of Optional Remote Valves Up to two (optional) Up to 3 ▶ Fluid CapacityFuel Tank Capacity 9.7 gal 8.5 gal Coolant Capacity 1.2 gal 5.5 qt Crankcase Capacity 1.1 gal 4.5 qt Transmission / Hydraulic System Capacity 9.2 gal 24.8 qt Front Axle Fluid Capacity 1.0 gal 4 qt ▶ PTO & HitchPTO Type Mechanical control; transmission clutch; wet disk brake (mid/rear PTO) Independent PTO Rear 540 rpm at 2800 rpm engine (rated) 540 rpm Mid-PTO Availability Not Published 2000 rpm Category, 3-Point Hitch Category I Category 1 Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 1,670 lb 1,356 lb Lift Control Type Position control Position Control ▶ Transmission & DrivetrainTransmission Type 8F/8R synchromesh shuttle shift gear transmission Hydrostatic No. of Speeds 8F/8R Infinite (2-range HST) Max Travel Speed (Forward) Not Published 15.4 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Single dry traction clutch Not Published Differential Lock & Limited Slip Options Differential lock: Yes Differential lock: Yes ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power Brakes Wet disk Wet Disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type MFWD (4WD) 4WD (MFWD) Front Axle Rating 1,940 lb 1,764 lb Drawbar Capacity 1,102 lb (static vertical load) Not Published ▶ Dimensions & ManeuverabilityOverall Width 57.3 in 55.1 in Wheelbase 62 in 67.8 in Ground Clearance 14 in 9.8 in (front axle) Min. Turn Radius without Brakes 6.9 ft (with brake applied) 98.4 in Height to Top of ROPS Not Published 92.3 in (R4 tires) Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 111.2 in 117.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,800 lb 2,910 lb (with all fluids) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial R1 Ag, R3 Turf, R4 Industrial, R3 Turf Radial R1 Agricultural - Front 7-14 7.00-12 R1 Agricultural - Rear 11.2-24 12.4-16 R3 Turf - Front 27X8.5-15 23x8.50-14 R3 Turf - Rear 41X14-20 14-17.5 R4 Industrial - Front 25X8.5-14 23x8.50-14 R4 Industrial - Rear 15-19.5 14-17.5 ▶ Loader & AttachmentsQuick Attach Loader System Quick-change attachment carrier 220R Loader (Quik-Park) Loader Model 300E 220R Loader Lift Height 84 in (at pivot pin) 85 in (at pivot pin) Loader Lift Capacity (Full Height) 1,186 lb (at pivot pin) 220R: 1,120 lb (at pivot pin, full height) Loader Breakout Force 1,704 lbf (at pivot pin) 1,949 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours
