▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV86CT-NJT2 3TNV88C-KJPT Engine Type Diesel 4-cycle, inline, water-cooled diesel, naturally aspirated No. of Cylinders 3 3 Displacement 95.7 in³ 100.1 in³ Rated Engine Speed 2500 rpm 2800 rpm Engine Power (Gross) 36.7 hp 34.2 hp PTO Power 30 hp 30.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water pump Liquid Air Cleaner Dry type with safety element Dual element Fuel System High pressure common rail direct injection Direct injection Alternator 55 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Implement/steering pump: Tandem gear; hydrostatic pump: PV axial piston Two single-section external gear pumps, one each side of engine timing-gear cover Implement Flow 5.3 gpm 4.8 gpm Steering Flow 4.0 gpm 3.6 gpm Total Hydraulic Flow 9.3 gpm Not Published Overall Hydraulic Pump Flow 9.3 gpm 10.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 2 (optional) Up to two (optional) ▶ Fluid CapacityFuel Tank Capacity 7.5 gal 10.0 gal Coolant Capacity 1.37 gal 1.2 gal Crankcase Capacity 4.5 qt 1.1 gal Transmission / Hydraulic System Capacity 5.5 gal 9.2 gal Front Axle Fluid Capacity 1.0 gal 1.0 gal ▶ PTO & HitchPTO Type Independent Mechanical control; transmission clutch; wet disk brake (mid/rear PTO) PTO Rear 540 rpm 540 rpm at 2800 rpm engine (rated) Mid-PTO Availability Optional Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,356 lb Not Published Hitch Lift Capacity (at 24”) 1356 lb 2081.2 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (HST) 8F/8R synchromesh shuttle shift gear transmission No. of Speeds Not Published 8F/8R Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Single dry traction clutch Differential Lock & Limited Slip Options Differential lock: Yes; Limited slip: Not Published Differential lock: Yes; limited slip: Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disk Wet disk Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published MFWD (4WD) Front Axle Rating 1760 lb 1940 lb Drawbar Capacity 880 lb 1102 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 115.9 in 111.2 in Overall Width 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) 57.3 in Wheelbase 62.8 in 62.6 in Ground Clearance 12.7 in (R4 tires) 13.0 in Min. Turn Radius without Brakes 9.4 ft (2.9 m) 6.9 ft (with brakes) (with brake applied) Height to Top of ROPS 95.3 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2266 lb 3166 lb Weight with ROPS and Loader 2972 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 7-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 27X8.50-15 27X8.5-15 R3 Turf - Rear 41X14-20 41X14-20 R4 Industrial - Front 25X8.50-14 or 27X8.50-15 25X8.5-14 R4 Industrial - Rear 15.00-19.5 or 43X16-20 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Quick-change attachment carrier Quick-change attachment carrier Loader Model D160 D160 Loader Lift Height 84 in 84.0 in Loader Lift Capacity (Full Height) 1,186 lb 1,186 lb Loader Breakout Force 1,704 lb 1,704 lb ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
