▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV86CT-NJT2 3TNV88-CR Engine Type Diesel 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 95.7 in³ 100.2 in³ Rated Engine Speed 2500 rpm 3000 rpm Engine Power (Gross) 36.7 hp 36.9 hp PTO Power 30 hp 30.2 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water pump Liquid-cooled Air Cleaner Dry type with safety element Dual dry Fuel System Not Published CRDI Alternator 55 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Tandem gear pump; hydrostatic pump: PV axial-piston pump Dual gear pump Implement Flow 5.3 gpm 6.1 gpm Steering Flow 4.0 gpm 4.4 gpm Total Hydraulic Flow 9.3 gpm 10.5 gpm Overall Hydraulic Pump Flow 9.3 gpm 10.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None No. of Optional Remote Valves Up to 2 (optional) 1 or 2 (single or double rear remote with detent, accessory) ▶ Fluid CapacityFuel Tank Capacity 7.5 gal 9.0 gal Coolant Capacity 5.5 qt 7.4 qt Crankcase Capacity 4.5 qt 6 qt Transmission / Hydraulic System Capacity 22 qt 8.5 gal Front Axle Fluid Capacity 4 qt 8.7 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not available Optional (Mid-PTO kit) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity Not Published 2,639 lb Hitch Lift Capacity (at 24”) 1,356 lb 1,558 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (HST) Mechanical No. of Speeds Not Published 12 forward / 12 reverse Max Travel Speed (Forward) Not Published 15.0 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Dry single plate Differential Lock & Limited Slip Options Differential lock: Yes Differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Unit frame: engine, clutch housing, transmission and front axle support bolted into one rigid assembly Steering Power steering Hydrostatic Brakes Wet disk Wet disc Seat Suspension & Adjustability Not Published Fore and aft sliding seat with cushion strength adjustment Front Axle Type Not Published 4WD center-pivot, reverse Elliott type Front Axle Rating 1,760 lb Not Published Drawbar Capacity 880 lb (maximum vertical load) Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) 53.5 in Wheelbase 62.8 in 64.5 in Ground Clearance 12.7 in (R4 tires) 12.8 in Min. Turn Radius without Brakes Not Published 116 in Height to Top of ROPS 95.3 in 94.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 115.9 in (with 3-point hitch) 126 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,222 lb 3,020 lb (with ROPS) Weight with ROPS and Loader 2,972 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 7-14 Farm Specialist 8.0-16 NHS TL 6PR R1 Agricultural - Rear 11.2-24 Farm Specialist 12.4-24 NHS TL 6PR (standard); Farm Specialist 11.2-24 NHS TL 6PR (option) R3 Turf - Front 27X8.50-15 27x10.5-15 R3 Turf - Rear 41X14-20 12.5-20 R4 Industrial - Front 25X8.50-14 or 27X8.50-15 27x10.5-15 R4 Industrial - Rear 15.00-19.5 or 43X16-20 12.5x20 ▶ Loader & AttachmentsQuick Attach Loader System Quick-change attachment carrier TX39H: quick attachment assembly Loader Model 300E TX39H Loader Lift Height 84 in (at pivot pin) TX39H: 101.5 in Loader Lift Capacity (Full Height) 1,186 lb (at pivot pin) TX39H: 2,116 lb (at pivot pin) Loader Breakout Force 1,704 lbf (at pivot pin) TX39H: 3,435 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours Basic 24 months or 2,000 hours, parts and labor; non-commercial: powertrain 72 months or 3,000 hours; rental and commercial: powertrain 36 months or 2,000 hours; loaders and backhoes 12 months ▶ ITC Company AccessoriesAccessories that fit None tagged yet
