▶ EngineEngine Manufacturer Yanmar Kubota Engine Model 3TNV86CT-MJT D1803-CR-E4-GL2 Engine Type Diesel, turbocharged Naturally aspirated, multi-valve, liquid-cooled diesel No. of Cylinders 3 3 Displacement 95.7 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 38.2 hp 37 hp PTO Power 31.1 hp 28 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water pump Liquid-cooled Air Cleaner Dry type with safety element Dry paper, dual element Fuel System Not Published Electronic CRS (Common Rail System) Alternator 75 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Implement/steering pump: dual gear pump; hydrostatic pump: PV axial-piston pump Tandem pump - gear type Implement Flow 9.1 gpm 9.4 gpm Steering Flow 6.2 gpm 4.7 gpm Total Hydraulic Flow 15.3 gpm 14.1 gpm Overall Hydraulic Pump Flow 15.3 gpm 14.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None standard (up to 3 optional) No. of Optional Remote Valves Not Published Optional, up to 3: double-acting valve or float detent valve, any position ▶ Fluid CapacityFuel Tank Capacity Open station (OOS): 13.5 gal; Cab: 11.8 gal 13.5 gal Coolant Capacity Open station (OOS): 1.4 gal; Cab: 1.9 gal 7.9 qt Crankcase Capacity 1.1 gal 7.1 qt Transmission / Hydraulic System Capacity 6.8 gal 11.1 gal Front Axle Fluid Capacity 1.3 gal 6.9 qt ▶ PTO & HitchPTO Type Independent Live independent (hydraulic clutch) PTO Rear 540 rpm 540 rpm @ 2476 engine rpm Mid-PTO Availability Optional (2100 rpm) Optional Category, 3-Point Hitch Limited Category I SAE Category I Hitch Lift Capacity 2,530 lb at hitch ball 3,750 lb Hitch Lift Capacity (at 24”) 2,200 lb 2,646 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type 3-range hydrostatic (eHydro) Hydrostatic No. of Speeds Infinite / 3 range 3-Range, 6 speeds (H-DS), infinitely variable in each Max Travel Speed (Forward) 18.50 mph 16.5 mph Max Travel Speed (Reverse) 18.50 mph 14.9 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Differential lock (traction assist) Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disk Wet disc type, mechanically activated Seat Suspension & Adjustability Not Published Suspension seat with swivel (standard); air-suspension seat (optional) Front Axle Type Mechanical front wheel drive (MFWD) 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating 3,196 lb Not Published Drawbar Capacity Not Published 1,433 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 120.2 in Not Published Overall Width 69.1 in 59.8 in Wheelbase 68.0 in 71.1 in Ground Clearance 12.2 in 13.5 in Min. Turn Radius without Brakes 8.8 ft (2.68 m, MFWD off) 8.9 ft (with brake applied) Height to Top of ROPS 93.3 in 97.2 in Height to Top of ROPS (folded) 72.0 in Not Published Height to Top of Cab Model 85.0 in Not Published ▶ WeightTractor Weight (Base) 2,900 lb 3,483 lb (DT ROPS); 3,494 lb (GST ROPS); 3,505 lb (HST ROPS); 3,880 lb (HSTC cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 7-14 7.0-16 R1 Agricultural - Rear 11.2-24 12.4-24 R3 Turf - Front 27X8.50-15 or 25/10.5LLX15 27x10.50-15 R3 Turf - Rear 41X14-20 or 41X18LL-16.1 41x18LL-16.1 R4 Industrial - Front 25X8.5-14 or 27X8.5-15 10-16.5 R4 Industrial - Rear 15-19.5 or 43X16-20 420/70-24 ▶ Loader & AttachmentsQuick Attach Loader System Tool-free attach-and-park mounting LA555: 2-lever mechanical quick coupler (standard); LA805: 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) Loader Model 300R; 320R LA555 or LA805 Loader Lift Height 300R: 90 in; 320R: 102 in LA555: 96.4 in; LA805: 104.7 in Loader Lift Capacity (Full Height) 300R: 1,360 lb; 320R: 1,598 lb (at pivot pin) LA555: 1,190 lb; LA805: 1,715 lb Loader Breakout Force 300R: 2,855 lbf; 320R: 3,327 lbf (at pivot pin) LA555: 2,030 lb; LA805: 2,549 lb (19.7 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
