Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
JohnDeere3039R
No photo
—
KubotaL3902
Comparison loaded for 2 tractors.
Spec
John Deere3039R
KubotaL3902
PTO Power
31.1 hp (23.2 kW) (manufacturer’s estimated)
DT (4WD): 32.1 hp (23.9 kW); HST (4WD): 30.3 hp (22.6 kW)
Alternator
12 V, 75 A
Not Published
Air Cleaner
Dry type with safety element (dual element)
Not Published
Engine Type
Diesel, turbocharged
Direct injection, vertical, water-cooled 4-cycle, diesel
Fuel System
High pressure common rail direct injection (HPCR)
Direct injection
Displacement
97.6 in³ (1600cc)
111.4 in³ (1826 cc)
No. of Cylinders
3
3
Rated Engine Speed
2600 rpm
2700 rpm
Cooling System Type
Liquid-cooled
Water-cooled
Engine Manufacturer
Yanmar
Kubota
Engine Emissions Constraints
Final Tier 4
Not Published
Engine Power (Gross vs. Net HP)
Gross: 38.2 hp (28.5 kW) @ 2600 rpm; Net: Not Published
Gross: 37.5 hp (28.0 kW); Net: 36.3 hp (27.1 kW)
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Applicable
Weight with ROPS and Loader
Not Published
Not Published
Pump Type
Tandem gear
Not Published
Steering Flow
16.7 L/min (4.4 gpm)
14.5 L/min (3.8 gpm)
Implement Flow
17.3 L/min (4.6 gpm)
23.9 L/min (6.3 gpm)
Total Hydraulic Flow
34 L/min (9 gpm)
38.4 L/min (10.1 gpm)
Hydraulic System Type
Open center
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
34 L/min (9 gpm)
38.4 L/min (10.1 gpm)
No. of Optional Remote Valves
Up to 6 rear remotes
Not Published
No. of Standard Remote Valves
Not Published
Not Published
R3 Turf - Rear
41X14-20 or 41X18LL-16.1
13.6-16
R3 Turf - Front
27X8.50-15 or 25/10.5LLX15
25X8.50-14
Tire Size & Options
R1 Bar, R3 Turf, R4 Industrial
R1 Agricultural; R3 Turf; R4 Industrial
R4 Industrial - Rear
15-19.5 or 43X16-20
15-19.5
R4 Industrial - Front
25X8.5-14 or 27X8.5-15
27X8.50-15
R1 Agricultural - Rear
11.2-24
11.2-24
R1 Agricultural - Front
7-14
7.2-16
PTO Rear
540 rpm
540 rpm
PTO Type
Independent
DT (4WD): Live-continuous running; HST (4WD): Live independent PTO with hydraulic clutch
Lift Control Type
Position control
Position control
Hitch Lift Capacity
2,530 lb (1,149 kg) at hitch ball
1998 lb (906 kg)
Mid-PTO Availability
Optional (eHydro only): 2100 rpm
Not Published
Category, 3-Point Hitch
Limited Category 1
SAE Category I
Hitch Lift Capacity (at 24”)
2,194 lb (995 kg) at 24 in behind link arms
1435 lb (651 kg)
Rear 3-Point Hitch Lift Capacity
2,530 lb (1,149 kg) at hitch ball
1998 lb (906 kg)
Coolant Capacity
Open station (OOS): 1.4 gal (5.3 L); Cab: 1.9 gal (7.0 L)
Not Published
Crankcase Capacity
1.1 gal (4.3 L) (with filter)
Not Published
Fuel Tank Capacity
Open station (OOS): 13.5 gal (51.1 L); Cab: 11.8 gal (44.5 L)
13.5 gal (51 L)
Front Axle Fluid Capacity
1.3 gal (4.8 L)
Not Published
Transmission / Hydraulic System Capacity
6.8 gal (25.7 L)
Not Published
Loader Lift Height
90 in (2,284 mm)
94.3 in (2394 mm)
Loader Breakout Force
2,855 lb (1,295 kg) at pivot; 2,032 lb (922 kg) @ 500 mm (19.7 in)
Not Published
Price for Backhoe Option
Not Published
BH77: $9,803 MSRP
Price for Mid-Mount Mower
Not Published
Not Applicable
Quick Attach Loader System
Quik-Park™ mounting system
Front Loader (LA526 — 2 Lever Quick Coupler (OPT))
Loader Lift Capacity (Full Height)
1,360 lb (617 kg) at pivot; 999 lb (453 kg) @ 500 mm ahead of pivot
1144.4 lb (519 kg)
Clutch
Not Published
DT (4WD): Dry type dual stage; HST (4WD): Not Applicable
Non-Commercial Home & Residential Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.
