▶ EngineEngine Manufacturer Yanmar Kubota Engine Model 3TNV86CT-KJPT V2403-CR-E4-GL2 Engine Type 4-cycle, inline, water-cooled diesel, turbocharged Naturally aspirated, multi-valve, liquid-cooled diesel No. of Cylinders 3 4 Displacement 95.8 in³ 148.5 in³ Rated Engine Speed 2800 rpm 2600 rpm Engine Power (Gross) 41.6 hp 42 hp PTO Power 36.3 hp 32.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid Liquid-cooled Air Cleaner Dry Dry paper, dual element Fuel System Direct injection Electronic CRS (Common Rail System) Alternator 55 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Two single-section external gear pumps, one either side of the engine Tandem pump - gear type Implement Flow 5.9 gpm 9.4 gpm Steering Flow 4.4 gpm 4.7 gpm Total Hydraulic Flow 10.3 gpm 14.1 gpm Overall Hydraulic Pump Flow 10.3 gpm 14.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None None standard (up to 3 optional) No. of Optional Remote Valves Loader mast mounted SCV (optional); 4th/5th SCV (optional) Optional, up to 3: double-acting valve or float detent valve, any position ▶ Fluid CapacityFuel Tank Capacity 9.7 gal 13.5 gal Coolant Capacity 1.3 gal 7.9 qt Crankcase Capacity 1.1 gal 8.7 qt Transmission / Hydraulic System Capacity 9.2 gal 11.4 gal Front Axle Fluid Capacity 1.0 gal 6.9 qt ▶ PTO & HitchPTO Type Transmission driven Live independent (hydraulic clutch) PTO Rear 540 rpm at 2800 rpm engine (rated) 540 rpm @ 2476 engine rpm Mid-PTO Availability Not Published Optional Category, 3-Point Hitch Category I SAE Category I Hitch Lift Capacity Not Published 3,858 lb Hitch Lift Capacity (at 24”) 1,670 lb 2,760 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type 8F/8R synchromesh shuttle shift gear transmission Hydrostatic No. of Speeds 8F/8R 3-Range, 6 speeds (H-DS), infinitely variable in each Max Travel Speed (Forward) 12.9 mph 16.8 mph Max Travel Speed (Reverse) Not Published 15.1 mph Clutch Single dry traction (mechanical) Not Published Differential Lock & Limited Slip Options Differential lock: Yes Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet disk Wet disc type, mechanically activated Seat Suspension & Adjustability Not Published Deluxe suspension seat with swivel (standard); Air-Ride seat (optional) Front Axle Type 4WD 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating 1,940 lb Not Published Drawbar Capacity 1,102 lb (maximum static vertical load) 1,433 lb ▶ Dimensions & ManeuverabilityOverall Width 57.3 in 66.5 in Wheelbase 62 in 74.6 in Ground Clearance 14 in 14.2 in Min. Turn Radius without Brakes 6.9 ft (with brake applied) 8.9 ft (with brake applied) Height to Top of ROPS Not Published 97.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published n/a (ROPS model) Overall Length 111.2 in 129.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,800 lb 3,759 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 7-14 8.3-16 R1 Agricultural - Rear 11.2-24 14.9-24 R3 Turf - Front 27X8.50-15 27-10.50LL15 R3 Turf - Rear Not Published 41-18LLx16.1 R4 Industrial - Front 25X8.50-14 10-16.5 R4 Industrial - Rear 15-19.5 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Quick-change attachment carrier 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) Loader Model D160 LA805 Loader Lift Height 84 in (at pivot pin) 104.7 in (at pivot pin) Loader Lift Capacity (Full Height) 1,186 lb (at pivot point, maximum height) 1,715 lb (at pivot pin) Loader Breakout Force 1,704 lbf (at pivot point) 2,549 lb ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
