▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV88-BMJT 3TNV88C-NJT2 Engine Type 3-cylinder liquid-cooled diesel, direct injection Diesel No. of Cylinders 3 3 Displacement 100.1 in³ 100.2 in³ Rated Engine Speed 2600 rpm 2500 rpm Engine Power (Gross) 32.4 hp 31.2 hp PTO Power 25 hp 24.2 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry type with safety element Dual element Fuel System Direct injection, self bleeding, in-line fuel pump with electric shutoff Direct injection Alternator 40 A 85 A, 12 V ▶ HydraulicsPump Type Dual tandem gear pump Tandem gear Implement Flow 8.6 gpm 5.3 gpm Steering Flow 5.3 gpm 4 gpm Total Hydraulic Flow 13.9 gpm 9.3 gpm Overall Hydraulic Pump Flow 13.9 gpm 9.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Up to 3 ▶ Fluid CapacityFuel Tank Capacity 13.5 gal (open station); 11.8 gal (cab) 8.5 gal Coolant Capacity 5.6 qt (open station); 7.4 qt (cab) 4.2 qt Crankcase Capacity 5.1 qt 4.7 qt Transmission / Hydraulic System Capacity 6.8 gal (eHydro); 6.3 gal (PowrReverser) 4.6 gal Front Axle Fluid Capacity 1.2 gal 4.1 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2100 rpm 2100 rpm Category, 3-Point Hitch Category 1 Category I Hitch Lift Capacity Not Published 1433 lb Hitch Lift Capacity (at 24”) 2200 lb 1356 lb Lift Control Type Position control Position Control ▶ Transmission & DrivetrainTransmission Type eHydro 3-range hydrostatic (4WD); PowrReverser 12F/12R power shuttle (4WD) Hydrostatic No. of Speeds Infinite forward and reverse, 3 ranges (eHydro); 12 forward, 12 reverse (PowrReverser) Infinite (2-range) Max Travel Speed (Forward) 19 mph (eHydro); 16.4 mph (PowrReverser) Not Published Max Travel Speed (Reverse) 19 mph (eHydro); 16.4 mph (PowrReverser) Not Published Clutch Multiple stage wet disc, 4.4 in (PowrReverser) Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock Differential lock ▶ Chassis, Steering & ControlsFrame Type Two-post folding ROPS; cab optional; MFWD standard Open station with foldable ROPS Steering Hydrostatic power steering Power Brakes Wet disk Wet Disc Seat Suspension & Adjustability Not Published Marine-grade seat Front Axle Type Mechanical front wheel drive (MFWD), standard, all ranges Not Published Front Axle Rating 1587 to 3197 lb 1940 lb Drawbar Capacity 562 lb 562 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 120.2 in 115.2 in Overall Width 52.4 in (minimum, R1 tires); 68.4 in (maximum, R1 tires) 55.6 in Wheelbase 68 in 65.2 in Ground Clearance Not Published 13 in Min. Turn Radius without Brakes Not Published 98.4 in Height to Top of ROPS 93.3 in 89.7 in Height to Top of ROPS (folded) Not Published 67.5 in Height to Top of Cab Model 89.4 in Not Published ▶ WeightTractor Weight (Base) 2900 lb (open station); 3570 lb (cab) 1973 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 bar tread, R3 turf, R4 industrial and golf tires available on all models R1 Ag, R3 Turf, R4 Industrial, R3 Turf Radial R1 Agricultural - Front 7.00-14 7.00-12 R1 Agricultural - Rear 11.2-24 12.4-16 R3 Turf - Front 27x8.50-15 23X8.50-14 R3 Turf - Rear 41x14.00-20 14-17.5 R4 Industrial - Front 25x8.50-14 or 27x8.50-15 23x8.50-14 R4 Industrial - Rear 43x16.00-20 or 15.00-19.5 14-17.5 ▶ Loader & AttachmentsQuick Attach Loader System John Deere quick-attach (Quik-Park); skid-steer style carrier optional on 300CX H130 Loader Loader Model 300X; 300CX; H160; H165; 300R; 320R H130 or 220R Loader Lift Height 300X: 90 in; 300CX: 102 in; H160: 90 in; H165: 102 in; 300R: 90 in; 320R: 102 in H130: 78.5 in; 220R: 85 in (at pivot pin) Loader Lift Capacity (Full Height) 300X: 1360 lb; 300CX: 1598 lb; H160: 1360 lb; H165: 1598 lb; 300R: 1360 lb; 320R: 1598 lb (to maximum height at pivot pin) H130: 1,027 lb; 220R: 1,120 lb (at pivot pin, full height) Loader Breakout Force 300X: 2855 lbf; 300CX: 3327 lbf; H160: 2855 lbf; H165: 3327 lbf; 300R: 2855 lbf; 320R: 3327 lbf (at pivot pin) H130: 2,363 lbf; 220R: 1,949 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
