▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV88-BMJT 3TNV88C-NJT2 Engine Type 3-cylinder liquid-cooled diesel, direct injection Diesel, naturally aspirated No. of Cylinders 3 3 Displacement 100.1 in³ 100.2 in³ Rated Engine Speed 2600 rpm 2500 rpm Engine Power (Gross) 32.4 hp 30.7 hp PTO Power 25 hp 25 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Water pump Air Cleaner Dry type with safety element Dry type with safety element Fuel System Direct injection, self bleeding, in-line fuel pump with electric shutoff High pressure common rail direct injection Alternator 40 A 55 A, 12 V ▶ HydraulicsPump Type Dual tandem gear pump Implement/steering pump: Tandem gear; hydrostatic pump: PV axial piston Implement Flow 8.6 gpm 5.3 gpm Steering Flow 5.3 gpm 4.0 gpm Total Hydraulic Flow 13.9 gpm 9.3 gpm Overall Hydraulic Pump Flow 13.9 gpm 10.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Up to 2 (optional) ▶ Fluid CapacityFuel Tank Capacity 13.5 gal (open station); 11.8 gal (cab) 7.5 gal Coolant Capacity 5.6 qt (open station); 7.4 qt (cab) 1.3 gal Crankcase Capacity 5.1 qt 4.5 qt Transmission / Hydraulic System Capacity 6.8 gal (eHydro); 6.3 gal (PowrReverser) 5.5 gal Front Axle Fluid Capacity 1.2 gal 1.0 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2100 rpm Not Published Category, 3-Point Hitch Category 1 Category I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 2200 lb 1356 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type eHydro 3-range hydrostatic (4WD); PowrReverser 12F/12R power shuttle (4WD) Hydrostatic (2-range) No. of Speeds Infinite forward and reverse, 3 ranges (eHydro); 12 forward, 12 reverse (PowrReverser) Infinite (2-range HST) Max Travel Speed (Forward) 19 mph (eHydro); 16.4 mph (PowrReverser) Not Published Max Travel Speed (Reverse) 19 mph (eHydro); 16.4 mph (PowrReverser) Not Published Clutch Multiple stage wet disc, 4.4 in (PowrReverser) Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Two-post folding ROPS; cab optional; MFWD standard Not Published Steering Hydrostatic power steering Power steering Brakes Wet disk Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Mechanical front wheel drive (MFWD), standard, all ranges 4WD (MFWD) Front Axle Rating 1587 to 3197 lb 1760 lb Drawbar Capacity 562 lb 880 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 120.2 in 115.9 in Overall Width 52.4 in (minimum, R1 tires); 68.4 in (maximum, R1 tires) 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) Wheelbase 68 in 62.8 in Ground Clearance Not Published 12.7 in (R4 tires) Min. Turn Radius without Brakes Not Published 9.4 ft (2.9 m) Height to Top of ROPS 93.3 in 95.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 89.4 in Not Published ▶ WeightTractor Weight (Base) 2900 lb (open station); 3570 lb (cab) 2266 lb Weight with ROPS and Loader Not Published 2972 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 bar tread, R3 turf, R4 industrial and golf tires available on all models R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 7.00-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 27x8.50-15 27X8.50-15 R3 Turf - Rear 41x14.00-20 41X14-20 R4 Industrial - Front 25x8.50-14 or 27x8.50-15 25X8.50-14 or 27X8.50-15 R4 Industrial - Rear 43x16.00-20 or 15.00-19.5 15.00-19.5 or 43X16-20 ▶ Loader & AttachmentsQuick Attach Loader System John Deere quick-attach (Quik-Park); skid-steer style carrier optional on 300CX Quick-change attachment carrier Loader Model 300X; 300CX; H160; H165; 300R; 320R D160 Loader Lift Height 300X: 90 in; 300CX: 102 in; H160: 90 in; H165: 102 in; 300R: 90 in; 320R: 102 in 84.0 in Loader Lift Capacity (Full Height) 300X: 1360 lb; 300CX: 1598 lb; H160: 1360 lb; H165: 1598 lb; 300R: 1360 lb; 320R: 1598 lb (to maximum height at pivot pin) 1,186 lb Loader Breakout Force 300X: 2855 lbf; 300CX: 3327 lbf; H160: 2855 lbf; H165: 3327 lbf; 300R: 2855 lbf; 320R: 3327 lbf (at pivot pin) 1,704 lb ▶ WarrantyWarranty Length & Coverage Not Published 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
